Ferrari 12 Cilindri Spider — [ENGINE] - B.15 - INJECTION CONTROL (diagram 0020)
Exploded view of the [engine] - b.15 - injection control on the Ferrari 12 Cilindri Spider, with 5 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri Spider [ENGINE] - B.15 - INJECTION CONTROL exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri-spider/0020.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 326909 | Ferrari Motorised Throttle Body - 326909 | $2,013.87 | Special order, ships in 7-14 days | |
| 1 | 925964 | Ferrari Motorised Throttle Body - 925964 | $1,893.26 | Special order, ships in 7-14 days |
| 2 | 316680 | Ferrari Spacer - 316680 | $270.44 | Special order, ships in 7-14 days |
| 3 | 987201 | Ferrari Screw Collar - 987201 | $69.92 | Special order, ships in 7-14 days |
| 4 | 231623 | Ferrari Screw M6 x 40 TCEI - 231623 | $1.02 | Available, ships in 3-6 days |
