Ferrari 12 Cilindri Spider — [MECHANICAL SYSTEM] - D.11 - FUEL TANK (diagram 0060)
Exploded view of the [mechanical system] - d.11 - fuel tank on the Ferrari 12 Cilindri Spider, with 22 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri Spider [MECHANICAL SYSTEM] - D.11 - FUEL TANK exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri-spider/0060.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 13046011 | Ferrari Flanged Nut - 13046011 | $0.73 | Available, ships in 3-6 days | |
| 181929 | Ferrari On-Off Valve - 181929 | $440.56 | Special order, ships in 7-14 days | |
| 1 | 892034 | Ferrari Compl. Fuel Tank - 892034 | $17,679.58 | Contact us to order |
| 2 | 237407 | Ferrari On-Off Valve - 237407 | $56.52 | Special order, ships in 7-14 days |
| 3 | 841837 | Ferrari Cpl Fuel Pump Flangia Sens. - 841837 | $2,545.70 | Special order, ships in 7-14 days |
| 4 | 841841 | Ferrari Cpl Fuel Pump E Flangia Pomp - 841841 | $2,381.25 | Special order, ships in 7-14 days |
| 5 | 254078 | Ferrari Clip - 254078 | $3.68 | Special order, ships in 7-14 days |
| 6 | 774704 | Ferrari Fuel Pump Inspection Cap - 774704 | $56.52 | Special order, ships in 7-14 days |
| 7 | 899649 | Ferrari O-Ring - 899649 | $32.76 | Special order, ships in 7-14 days |
| 8 | 829187 | Ferrari Fls E Adattatore Angolare - 829187 | $934.32 | Special order, ships in 7-14 days |
| 9 | 256323 | Ferrari Screw 5x16 - 256323 | $0.98 | Available, ships in 3-6 days |
| 10 | 11001124 | Ferrari Stud Bolt - 11001124 | $137.67 | Available, ships in 3-6 days |
| 11 | 774582 | Ferrari Compl. Rear Inspection Cover - 774582 | $191.76 | Special order, ships in 7-14 days |
| 12 | 14040514 | Ferrari Flanged Nut - 14040514 | Superseded | Order 13046011 instead |
| 13 | 844589 | Ferrari Fuel Filler Neck Compl. With - 844589 | $1,647.38 | Special order, ships in 7-14 days |
| 14 | 791355 | Ferrari Screw - 791355 | $10.02 | Special order, ships in 7-14 days |
| 15 | 961902 | Ferrari Fuel Delivery Pipe From Tank - 961902 | $516.33 | Special order, ships in 7-14 days |
| 16 | 239094 | Ferrari Clip - 239094 | $2.59 | Special order, ships in 7-14 days |
| 17 | 835657 | Ferrari Underbody Fuel Delivery Pipe - 835657 | $213.88 | Special order, ships in 7-14 days |
| 18 | 921179 | Ferrari CLIP - 921179 | Price on request | Contact us for price and availability |
| 19 | 987836 | Ferrari Front Fuel Delivery Pipe - 987836 | $78.66 | Special order, ships in 7-14 days |
| 20 | 81840800 | Ferrari Clip - 81840800 | $0.79 | Special order, ships in 7-14 days |
