Ferrari 12 Cilindri Spider — [VEHICLE TRIM] - E.04 - TONNEAU COVER (diagram 0100)
Exploded view of the [vehicle trim] - e.04 - tonneau cover on the Ferrari 12 Cilindri Spider, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri Spider [VEHICLE TRIM] - E.04 - TONNEAU COVER exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri-spider/0100.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 80415900 | Ferrari Screw - 80415900 | $32.60 | Available, ships in 3-6 days | |
| 13578311 | Ferrari Washer - 13578311 | Superseded | Order 13578324 instead | |
| 1 | 985992338 | Ferrari COMPL. TONNEAU COVER - 985992338 | $16,858.07 | Special order, ships in 7-14 days |
| 2 | 992363 | Ferrari COMPL. RH HINGE - 992363 | Price on request | Contact us for price and availability |
| 3 | 992364 | Ferrari COMPL. LH HINGE - 992364 | Price on request | Contact us for price and availability |
| 4 | 11617624 | Ferrari Screw - 11617624 | Superseded | Order 16287224 instead |
| 4 | 16287224 | Ferrari Screw M8x25 - 16287224 | $0.82 | Available, ships in 3-6 days |
| 5 | 13578324 | Ferrari Washer 8.15-24x 2 - 13578324 | $0.44 | Available, ships in 3-6 days |
| 6 | 12625221 | Ferrari Washer - 12625221 | $0.17 | Available, ships in 3-6 days |
| 6 | 12625224 | Ferrari Washer - 12625224 | $0.13 | Available, ships in 3-6 days |
