Ferrari 12 Cilindri Spider — [VEHICLE TRIM] - E.06 - LATERAL SUBSTRUCTURE (diagram 0102)

Exploded view of the [vehicle trim] - e.06 - lateral substructure on the Ferrari 12 Cilindri Spider, with 38 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 12 Cilindri Spider [VEHICLE TRIM] - E.06 - LATERAL SUBSTRUCTURE exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
12643711Ferrari Washer - 12643711SupersededOrder 12643724 instead
12643721Ferrari Washer - 12643721SupersededOrder 12643724 instead
14499301Ferrari Washer - 14499301SupersededOrder 12643724 instead
1985774451Ferrari LOWER RH DOOR SEAL PROFILE - 985774451Price on requestContact us for price and availability
2985774454Ferrari LOWER LH DOOR SEAL PROFILE - 985774454Price on requestContact us for price and availability
3985774423Ferrari PROFILE LINKING RH A-PILLAR WITH FLANK - 985774423Price on requestContact us for price and availability
4985774426Ferrari PROFILE LINKING LH A-PILLAR WITH FLANK - 985774426Price on requestContact us for price and availability
5985774443Ferrari PROFILE LINKING RH B-PILLAR WITH FLANK - 985774443Price on requestContact us for price and availability
6985774447Ferrari PROFILE LINKING LH B-PILLAR WITH FLANK - 985774447$758.79Special order, ships in 7-14 days
7985994028Ferrari LH FLAP, POINTS P-P1 - 985994028Price on requestContact us for price and availability
7985994029Ferrari RH FLAP, POINTS P-P1 - 985994029Price on requestContact us for price and availability
8993413Ferrari LH B-PILLAR - 993413$1,352.32Special order, ships in 7-14 days
8993427Ferrari RH B-PILLAR - 993427$1,352.32Special order, ships in 7-14 days
9985994019Ferrari LH B-PILLAR LOWER REAR LINER - 985994019Price on requestContact us for price and availability
9985994020Ferrari RH B-PILLAR LOWER REAR LINER - 985994020Price on requestContact us for price and availability
10985996326Ferrari COMPL. MOUNT OF LOWER REAR CLADDING FOR LH B-PILLAR - 985996326Price on requestContact us for price and availability
10985996331Ferrari COMPL. MOUNT OF LOWER REAR CLADDING FOR RH B-PILLAR - 985996331Price on requestContact us for price and availability
11950099Ferrari LH Bracket - 950099$44.24Special order, ships in 7-14 days
11950100Ferrari RH Bracket - 950100$44.24Special order, ships in 7-14 days
1268176500Ferrari Screw 5x20 - 68176500$1.02Available, ships in 3-6 days
1312643724Ferrari/Maserati Washer - 12643724$0.20In stock
14242255Ferrari Shim 1.0mm - 242255$6.94Special order, ships in 7-14 days
1489143000Ferrari Shim 1.0mm Interasse 25Mm - 89143000$12.44Special order, ships in 7-14 days
15985994016Ferrari FRONT SECTION OF LH REAR WHEELHOUSE - 985994016Price on requestContact us for price and availability
15985994017Ferrari FRONT SECTION OF RH REAR WHEELHOUSE - 985994017Price on requestContact us for price and availability
16856363Ferrari LH Rear WheeLHouse Connector - 856363$130.29Special order, ships in 7-14 days
16856379Ferrari RH Rear WheeLHouse Connector - 856379$130.29Special order, ships in 7-14 days
17951610Ferrari LH Bracket - 951610$211.43Special order, ships in 7-14 days
17951614Ferrari RH Bracket - 951614$211.43Special order, ships in 7-14 days
18985994018Ferrari RH ANGLE PIECE - 985994018Price on requestContact us for price and availability
19985994023Ferrari LH ANGLE PIECE - 985994023$587.44Special order, ships in 7-14 days
20985994024Ferrari RH ANGLE PIECE - 985994024Price on requestContact us for price and availability
21955001719Ferrari COMPL. REAR ELEMENT OF RH LATERAL SUBSTRUCTURE - 955001719$758.79Special order, ships in 7-14 days
22955001720Ferrari COMPL. REAR ELEMENT OF LH LATERAL SUBSTRUCTURE - 955001720$758.79Special order, ships in 7-14 days
23985774455Ferrari Lower Rear Element Of RH Lat - 985774455$442.56Special order, ships in 7-14 days
24985774456Ferrari Lower Rear Element Of LH Lat - 985774456$442.56Special order, ships in 7-14 days
25985774410Ferrari LH FRONT A-PILLAR FLANGE - 985774410Price on requestContact us for price and availability
25985774406Ferrari RH FRONT A-PILLAR FLANGE - 985774406Price on requestContact us for price and availability

All 12 Cilindri Spider diagrams
