Ferrari 12 Cilindri Spider — [VEHICLE TRIM] - E.12 - ROLLBAR (diagram 0108)
Exploded view of the [vehicle trim] - e.12 - rollbar on the Ferrari 12 Cilindri Spider, with 27 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri Spider [VEHICLE TRIM] - E.12 - ROLLBAR exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri-spider/0108.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 81911200 | Ferrari Screw - 81911200 | Superseded | Order 85692200 instead | |
| 68176300 | Ferrari Screw 5x12 - 68176300 | Superseded | Order 85692200 instead | |
| 12640606 | Ferrari Washer - 12640606 | Superseded | Order 12640678 instead | |
| 12640608 | Ferrari Washer - 12640608 | Superseded | Order 12640678 instead | |
| 12640677 | Ferrari Washer - 12640677 | Superseded | Order 12640678 instead | |
| 124338 | Ferrari Washer D. 8 - 25 x 3 - 124338 | $14.55 | Available, ships in 3-6 days | |
| 1 | 996873 | Ferrari CONTAINER TUB - 996873 | $223.73 | Special order, ships in 7-14 days |
| 2 | 996883 | Ferrari HYDRAULIC PUMP COVER - 996883 | $223.73 | Special order, ships in 7-14 days |
| 3 | 86276300 | Ferrari SCREW - 86276300 | $7.84 | Special order, ships in 7-14 days |
| 4 | 12640678 | Ferrari Washer 6.15x25x2 - 12640678 | $3.47 | Available, ships in 3-6 days |
| 5 | 84324400 | Ferrari COSMETIC CAP - 84324400 | $2.36 | Available, ships in 3-6 days |
| 6 | 55015522 | Ferrari Compl. Roll Bar Water Protection Plug - 55015522 | Superseded | Order 55070744 instead |
| 6 | 55070744 | Ferrari Compl. Roll Bar Water Protection Plug - 55070744 | $565.49 | Special order, ships in 7-14 days |
| 7 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 8 | 911975 | Ferrari Flat Washer D 5.15-15X - 911975 | $0.79 | Special order, ships in 7-14 days |
| 9 | 993473 | Ferrari F167RHt_Rinf_Colleg_Mont. B - 993473 | $1,155.62 | Special order, ships in 7-14 days |
| 10 | 993465 | Ferrari F167RHt_Rinf_Colleg_Mont. B - 993465 | $1,155.62 | Special order, ships in 7-14 days |
| 11 | 277287 | Ferrari Screw M10 x 1.25 x 40 - 277287 | $32.76 | Available, ships in 3-6 days |
| 12 | 247857 | Ferrari Screw 8x35 - 247857 | $4.12 | Available, ships in 3-6 days |
| 13 | 219344 | Ferrari Washer D8.5x24x - 219344 | Superseded | Order 124338 instead |
| 14 | 791263 | Ferrari Flanged Screw M6 x 45 - 791263 | $0.82 | Special order, ships in 7-14 days |
| 15 | 996882 | Ferrari COMPL. HYDRAULIC PUMP BRACKET - 996882 | $270.44 | Special order, ships in 7-14 days |
| 16 | 55000009 | Ferrari Tubo Scolo Acqua - 55000009 | $90.95 | Special order, ships in 7-14 days |
| 17 | 331573 | Ferrari Ring Clamp - 331573 | $0.71 | Special order, ships in 7-14 days |
| 18 | 278577 | Ferrari Tube Clamp D.30-40mm - 278577 | $3.68 | Special order, ships in 7-14 days |
| 19 | 55003316 | Ferrari Bracket - 55003316 | $46.69 | Special order, ships in 7-14 days |
| 20 | 85692200 | Ferrari SCREW M5 x 12 - 85692200 | $0.65 | Available, ships in 3-6 days |
