Ferrari 12 Cilindri Spider — [VEHICLE TRIM] - E.13.04 - ROOF - HYDRAULICS (diagram 0112)

Exploded view of the [vehicle trim] - e.13.04 - roof - hydraulics on the Ferrari 12 Cilindri Spider, with 4 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 12 Cilindri Spider [VEHICLE TRIM] - E.13.04 - ROOF - HYDRAULICS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
1903686Ferrari Complete Hydraulic System Kit - 903686$18,044.06Special order, ships in 7-14 days
3903676Ferrari Roof Wiring Harness - 903676$1,032.68Special order, ships in 7-14 days
455000933Ferrari ROOF ECU - 55000933Price on requestContact us for price and availability
584603200Ferrari Hydraulic System Fastener Kit - 84603200$115.54Special order, ships in 7-14 days

All 12 Cilindri Spider diagrams
