Ferrari 12 Cilindri Spider — [VEHICLE TRIM] - E.25 - WINDSCREEN (diagram 0124)
Exploded view of the [vehicle trim] - e.25 - windscreen on the Ferrari 12 Cilindri Spider, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri Spider [VEHICLE TRIM] - E.25 - WINDSCREEN exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri-spider/0124.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 783977 | Ferrari Compl. LH Underwindscreen Tr - 783977 | Superseded | Order 55055738 instead | |
| 856918 | Ferrari Compl. RH Underwindscreen Tr - 856918 | Superseded | Order 55055747 instead | |
| 1 | 985996542 | Ferrari Compl. Windscreen - 985996542 | $5,170.51 | Contact us to order |
| 1 | 985996543 | Ferrari Compl. Windscreen - 985996543 | $7,277.47 | Contact us to order |
| 2 | 55055747 | Ferrari Compl. RH Underwindscreen Tray - 55055747 | $1,721.15 | Special order, ships in 7-14 days |
| 2 | 783976 | Ferrari Compl. RH Underwindscreen Tray - 783976 | $1,426.08 | Special order, ships in 7-14 days |
| 3 | 55055738 | Ferrari Compl. LH Underwindscreen Tray - 55055738 | $1,426.08 | Special order, ships in 7-14 days |
| 3 | 856650 | Ferrari Compl. LH Underwindscreen Tray - 856650 | $1,671.97 | Special order, ships in 7-14 days |
| 4 | 872926 | Ferrari Striker Fastener Screw M5 - 872926 | $30.57 | Special order, ships in 7-14 days |
| 5 | 783984 | Ferrari Compl. Battery Cover - 783984 | $639.27 | Special order, ships in 7-14 days |
| 5 | 857045 | Ferrari Compl. Battery Cover - 857045 | $1,573.62 | Special order, ships in 7-14 days |
| 6 | 256490 | Ferrari Screw TBEI M5 x 16 - 256490 | $3.91 | Available, ships in 3-6 days |
