Ferrari 12 Cilindri Spider — [VEHICLE TRIM] - E.32 - DOOR SEALS (diagram 0133)
Exploded view of the [vehicle trim] - e.32 - door seals on the Ferrari 12 Cilindri Spider, with 19 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri Spider [VEHICLE TRIM] - E.32 - DOOR SEALS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri-spider/0133.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 996893 | Ferrari Guarnizione Contorno Porta D - 996893 | $1,376.91 | Special order, ships in 7-14 days |
| 1 | 996894 | Ferrari Guarnizioni Contorno Porta S - 996894 | $1,376.91 | Special order, ships in 7-14 days |
| 2 | 16285127 | Ferrari Screw M5 x 16 - 16285127 | $1.05 | Special order, ships in 7-14 days |
| 3 | 263276 | Ferrari Washer - 263276 | $0.33 | Available, ships in 3-6 days |
| 4 | 89336000 | Ferrari Shim Plate - 89336000 | $9.16 | Special order, ships in 7-14 days |
| 5 | 996892 | Ferrari Guarnizione Anello Parabrezz - 996892 | $2,206.39 | Special order, ships in 7-14 days |
| 6 | 984257 | Ferrari LH Mirror Triangle Trim Seal - 984257 | $172.63 | Special order, ships in 7-14 days |
| 6 | 984258 | Ferrari RH Mirror Triangle Trim Seal - 984258 | $172.63 | Special order, ships in 7-14 days |
| 7 | 786687 | Ferrari LH Door Beltline Seal - 786687 | $1,005.35 | Special order, ships in 7-14 days |
| 7 | 786688 | Ferrari RH Door Beltline Seal - 786688 | $1,005.35 | Special order, ships in 7-14 days |
| 8 | 15689809 | Ferrari Screw D. 4.2 x 19 TBFIC - 15689809 | $0.27 | Available, ships in 3-6 days |
| 9 | 14115885 | Ferrari Fixing Block - 14115885 | $0.31 | Available, ships in 3-6 days |
| 10 | 786713 | Ferrari LH Front Window Scraper - 786713 | $743.07 | Special order, ships in 7-14 days |
| 10 | 786714 | Ferrari RH Front Window Scraper - 786714 | $743.07 | Special order, ships in 7-14 days |
| 11 | 55014517 | Ferrari LH Door Seal Buffer - 55014517 | $83.57 | Special order, ships in 7-14 days |
| 11 | 55014518 | Ferrari RH Door Seal Buffer - 55014518 | $83.57 | Special order, ships in 7-14 days |
| 12 | 16296924 | Ferrari Screw M6 x 14 TE - 16296924 | $0.54 | Available, ships in 3-6 days |
| 13 | 85833800 | Ferrari Screw M5 x 14 TBFTX - 85833800 | $0.90 | Available, ships in 3-6 days |
| 14 | 62769800 | Ferrari Washer - 62769800 | $0.44 | Available, ships in 3-6 days |
