Ferrari 12 Cilindri Spider — [VEHICLE TRIM] - E.33 - FRONT LID TRIM (diagram 0134)
Exploded view of the [vehicle trim] - e.33 - front lid trim on the Ferrari 12 Cilindri Spider, with 26 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri Spider [VEHICLE TRIM] - E.33 - FRONT LID TRIM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri-spider/0134.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 63402800 | Ferrari Ball Pin - 63402800 | Superseded | Order 85216400 instead | |
| 69205900 | Ferrari Ball Pin - 69205900 | Superseded | Order 85216400 instead | |
| 64577200 | Ferrari Pin - 64577200 | Superseded | Order 85216400 instead | |
| 65939900 | Ferrari Pin - 65939900 | Superseded | Order 85216400 instead | |
| 1 | 787279 | Ferrari Engine Compartment Lid Insul - 787279 | $442.56 | Special order, ships in 7-14 days |
| 2 | 820525 | Ferrari RH Engine Compartment Lid In - 820525 | $137.67 | Special order, ships in 7-14 days |
| 3 | 820524 | Ferrari LH Engine Compartment Lid In - 820524 | $137.67 | Special order, ships in 7-14 days |
| 4 | 787264 | Ferrari Compl. RH Air Vent Bezel - 787264 | $614.67 | Special order, ships in 7-14 days |
| 5 | 787259 | Ferrari Compl. LH Air Vent Bezel - 787259 | $614.67 | Special order, ships in 7-14 days |
| 6 | 14591687 | Ferrari Fixing Button - 14591687 | $0.13 | Available, ships in 3-6 days |
| 7 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 7 | 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days |
| 8 | 958106 | Ferrari Luggage Compartment Lid Lower Damper - 958106 | $18.17 | Special order, ships in 7-14 days |
| 9 | 958109 | Ferrari Luggage Compartment Lid Upper Damper - 958109 | $41.76 | Special order, ships in 7-14 days |
| 10 | 917622 | Ferrari Lock Without Safety Retainer - 917622 | $442.56 | Special order, ships in 7-14 days |
| 11 | 55030265 | Ferrari RH Front Lid Lock Striker - 55030265 | $130.29 | Special order, ships in 7-14 days |
| 12 | 55030266 | Ferrari LH Front Lid Lock Striker - 55030266 | $130.29 | Special order, ships in 7-14 days |
| 13 | 787285 | Ferrari Compl. Lid Release Cable - 787285 | $393.38 | Special order, ships in 7-14 days |
| 13 | 860193 | Ferrari Compl. Lid Release Cable - 860193 | $393.38 | Special order, ships in 7-14 days |
| 14 | 881431 | Ferrari Viti Serratura Cebi - 881431 | $7.40 | Special order, ships in 7-14 days |
| 15 | 987050 | Ferrari Clip - 987050 | $6.31 | Special order, ships in 7-14 days |
| 16 | 14304428 | Ferrari Screw - 14304428 | $0.59 | Special order, ships in 7-14 days |
| 17 | 291408 | Ferrari Clip - 291408 | $0.34 | Special order, ships in 7-14 days |
| 18 | 915623 | Ferrari Front Gas Strut - 915623 | $74.29 | Special order, ships in 7-14 days |
| 19 | 85216400 | Ferrari Pin - 85216400 | $2.98 | In stock |
| 20 | 13046112 | Ferrari Nut - 13046112 | $0.46 | Available, ships in 3-6 days |
