Ferrari 12 Cilindri Spider — [ELECTRICAL SYSTEM] - F.09 - LIGHTING SYSTEMS (diagram 0184)
Exploded view of the [electrical system] - f.09 - lighting systems on the Ferrari 12 Cilindri Spider, with 34 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri Spider [ELECTRICAL SYSTEM] - F.09 - LIGHTING SYSTEMS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri-spider/0184.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 748857 | Ferrari Luggage Compartment Light - 748857 | Superseded | Order 974896 instead | |
| 911486 | Ferrari Luggage Compartment Light - 911486 | Superseded | Order 974896 instead | |
| 12643711 | Ferrari Washer - 12643711 | Superseded | Order 12643724 instead | |
| 12643721 | Ferrari Washer - 12643721 | Superseded | Order 12643724 instead | |
| 14499301 | Ferrari Washer - 14499301 | Superseded | Order 12643724 instead | |
| 1 | 774223 | Ferrari RH Headlamp - 774223 | $6,250.83 | Special order, ships in 7-14 days |
| 1 | 957519 | Ferrari RH Headlamp - 957519 | $6,513.11 | Special order, ships in 7-14 days |
| 1 | 967005 | Ferrari RH Headlamp - 967005 | $6,227.93 | Special order, ships in 7-14 days |
| 1 | 967007 | Ferrari RH Headlamp - 967007 | $6,411.10 | Special order, ships in 7-14 days |
| 1 | 967010 | Ferrari RH Headlamp - 967010 | $6,490.20 | Special order, ships in 7-14 days |
| 1 | 967011 | Ferrari RH Headlamp - 967011 | $6,665.05 | Special order, ships in 7-14 days |
| 2 | 774222 | Ferrari LH Headlamp - 774222 | $6,250.83 | Special order, ships in 7-14 days |
| 2 | 957520 | Ferrari LH Headlamp - 957520 | $6,513.11 | Special order, ships in 7-14 days |
| 2 | 967008 | Ferrari LH Headlamp - 967008 | $6,227.93 | Special order, ships in 7-14 days |
| 2 | 967009 | Ferrari LH Headlamp - 967009 | $6,411.10 | Special order, ships in 7-14 days |
| 2 | 967013 | Ferrari LH Headlamp - 967013 | $6,490.20 | Special order, ships in 7-14 days |
| 2 | 967018 | Ferrari LH Headlamp - 967018 | $6,665.05 | Special order, ships in 7-14 days |
| 3 | 14305834 | Ferrari Screw 6X40 - 14305834 | $1.36 | Available, ships in 3-6 days |
| 3 | 231623 | Ferrari Screw M6 x 40 TCEI - 231623 | $1.02 | Available, ships in 3-6 days |
| 4 | 68040000 | Ferrari Washer 6X20x2 - 68040000 | $0.27 | Available, ships in 3-6 days |
| 5 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
| 6 | 808395 | Ferrari Third Brake Light - 808395 | $1,661.04 | Special order, ships in 7-14 days |
| 7 | 774220 | Ferrari RH Tail Light - 774220 | $1,770.31 | Special order, ships in 7-14 days |
| 7 | 977790 | Ferrari RH Tail Light - 977790 | $1,682.89 | Special order, ships in 7-14 days |
| 8 | 774221 | Ferrari LH Tail Light - 774221 | $1,770.31 | Special order, ships in 7-14 days |
| 8 | 977793 | Ferrari LH Tail Light - 977793 | $1,682.89 | Special order, ships in 7-14 days |
| 9 | 10977924 | Ferrari Screw - 10977924 | $1.04 | Special order, ships in 7-14 days |
| 10 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 11 | 85834000 | Ferrari Screw M5 x 25 - 85834000 | $0.71 | Special order, ships in 7-14 days |
| 12 | 911975 | Ferrari Flat Washer D 5.15-15X - 911975 | $0.79 | Special order, ships in 7-14 days |
| 13 | 974896 | Ferrari Luggage Compartment Light - 974896 | $98.32 | Special order, ships in 7-14 days |
| 14 | 941841 | Ferrari Front Light Unit - 941841 | $4,055.85 | Special order, ships in 7-14 days |
| 15 | 911487 | Ferrari 1Led Courtesy Light - 911487 | $46.69 | Special order, ships in 7-14 days |
| 16 | 318013 | Ferrari Light Unit - 318013 | $61.45 | Special order, ships in 7-14 days |
