Ferrari 12 Cilindri — [ENGINE] - B.07 - TORSION DAMPER (diagram 0010)
Exploded view of the [engine] - b.07 - torsion damper on the Ferrari 12 Cilindri, with 3 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri [ENGINE] - B.07 - TORSION DAMPER exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri/0010.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 898941 | Ferrari Torsion Damper - 898941 | $3,458.71 | Special order, ships in 7-14 days |
| 2 | 907356 | Ferrari Washer - 907356 | $26.20 | Special order, ships in 7-14 days |
| 3 | 196216 | Ferrari Screw For Damper Fixing - 196216 | $144.23 | Special order, ships in 7-14 days |
