Ferrari 12 Cilindri — [ENGINE] - B.33 - ALTERNATOR DRIVE (diagram 0038)
Exploded view of the [engine] - b.33 - alternator drive on the Ferrari 12 Cilindri, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri [ENGINE] - B.33 - ALTERNATOR DRIVE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri/0038.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14306621 | Ferrari Screw 8X35 - 14306621 | Superseded | Order 14306624 instead | |
| 1 | 833197 | Ferrari Alternator Drive Belt - 833197 | $113.62 | Special order, ships in 7-14 days |
| 2 | 916494 | Ferrari Smooth Pulley - 916494 | $179.46 | Special order, ships in 7-14 days |
| 3 | 14306624 | Ferrari Screw 8x35mm - 14306624 | $0.52 | Special order, ships in 7-14 days |
| 4 | 11186374 | Ferrari Washer - 11186374 | $2.13 | Special order, ships in 7-14 days |
| 5 | 921207 | Ferrari Bush - 921207 | $17.67 | Special order, ships in 7-14 days |
| 6 | 923826 | Ferrari TIGHTENER MOUNT BUSH - 923826 | Price on request | Contact us for price and availability |
| 7 | 290251 | Ferrari Screw M8 x 1.25 x 94 - 290251 | $86.04 | Special order, ships in 7-14 days |
| 8 | 961815 | Ferrari Belt Tightener Mount - 961815 | $417.97 | Special order, ships in 7-14 days |
| 9 | 289759 | Ferrari Calibrated Screw 6X1 - 289759 | $20.09 | Special order, ships in 7-14 days |
