Ferrari 12 Cilindri — [MECHANICAL SYSTEM] - D.07 - EXHAUST MANIFOLD (diagram 0055)
Exploded view of the [mechanical system] - d.07 - exhaust manifold on the Ferrari 12 Cilindri, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri [MECHANICAL SYSTEM] - D.07 - EXHAUST MANIFOLD exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri/0055.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 880349 | Ferrari Collett. Di Scaric0 Sx Con S - 880349 | $6,819.08 | Special order, ships in 7-14 days | |
| 1 | 774713 | Ferrari LH Exhaust Manifold - 774713 | $7,324.90 | Special order, ships in 7-14 days |
| 1 | 971027 | Ferrari RH Exhaust Manifold - 971027 | $10,277.82 | Special order, ships in 7-14 days |
| 2 | 212702 | Ferrari Exhaust Manifold Gasket - 212702 | $13.60 | In stock |
| 3 | 210971 | Ferrari Copper Exhaust Nut - 210971 | $3.25 | In stock |
| 4 | 788373 | Ferrari Front LH Head Heat Shield - 788373 | $467.15 | Special order, ships in 7-14 days |
| 4 | 788378 | Ferrari Front RH Head Heat Shield - 788378 | $467.15 | Special order, ships in 7-14 days |
| 5 | 788372 | Ferrari Rear LH Head Heat Shield - 788372 | $516.33 | Special order, ships in 7-14 days |
| 5 | 788374 | Ferrari Rear RH Head Heat Shield - 788374 | $516.33 | Special order, ships in 7-14 days |
| 6 | 233600 | Ferrari/Maserati Screw - 233600 | $1.98 | In stock |
| 7 | 11625524 | Ferrari Screw - 11625524 | $1.53 | Special order, ships in 7-14 days |
