Ferrari 12 Cilindri — [MECHANICAL SYSTEM] - D.12 - TANK MOUNTS (diagram 0061)
Exploded view of the [mechanical system] - d.12 - tank mounts on the Ferrari 12 Cilindri, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri [MECHANICAL SYSTEM] - D.12 - TANK MOUNTS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri/0061.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 887667 | Ferrari Tank Heat Shield - 887667 | $614.67 | Special order, ships in 7-14 days |
| 2 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 3 | 774403 | Ferrari Compl. RH Upper Retainer - 774403 | $71.28 | Special order, ships in 7-14 days |
| 4 | 774399 | Ferrari Compl. LH Upper Retainer - 774399 | $71.28 | Special order, ships in 7-14 days |
| 5 | 792394 | Ferrari Screw TE M6 x 18 - 792394 | $0.84 | Available, ships in 3-6 days |
| 6 | 228265 | Ferrari Nut 6x1x9 - 228265 | $0.40 | Available, ships in 3-6 days |
| 7 | 250645 | Ferrari Ring Nut - 250645 | $1.44 | Special order, ships in 7-14 days |
| 8 | 794712 | Ferrari Tank Heat Insulation Bracket - 794712 | $36.86 | Special order, ships in 7-14 days |
| 9 | 944047 | Ferrari Compl. RH Lower Retainer - 944047 | $154.89 | Special order, ships in 7-14 days |
| 10 | 943944 | Ferrari Compl. LH Lower Retainer - 943944 | $159.79 | Special order, ships in 7-14 days |
| 11 | 16287024 | Ferrari Screw - 16287024 | $1.00 | In stock |
