Ferrari 12 Cilindri — [MECHANICAL SYSTEM] - D.18 - LIFTING THE VEHICLE (diagram 0067)
Exploded view of the [mechanical system] - d.18 - lifting the vehicle on the Ferrari 12 Cilindri, with 33 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri [MECHANICAL SYSTEM] - D.18 - LIFTING THE VEHICLE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri/0067.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 293146 | Ferrari Clip - 293146 | $2.09 | Special order, ships in 7-14 days | |
| 335415 | Ferrari Electric Pump - 335415 | Superseded | Order 844232 instead | |
| 255049 | Ferrari Screw 10x1.5x32 - 255049 | Superseded | Order 304224 instead | |
| 1 | 844232 | Ferrari Electric Pump - 844232 | $5,688.03 | Special order, ships in 7-14 days |
| 2 | 285319 | Ferrari Insulation - 285319 | $233.56 | Special order, ships in 7-14 days |
| 3 | 889559 | Ferrari Pump Mounting Bracket - 889559 | $199.14 | Special order, ships in 7-14 days |
| 4 | 763297 | Ferrari RIGID PIPE - 763297 | Price on request | Contact us for price and availability |
| 5 | 919742 | Ferrari Tubo Flessibile Riempimento - 919742 | $206.52 | Special order, ships in 7-14 days |
| 6 | 258573 | Ferrari Reservoir - 258573 | $86.04 | Special order, ships in 7-14 days |
| 7 | 304224 | Ferrari Screw 10x1.5x28 - 304224 | $30.57 | Special order, ships in 7-14 days |
| 8 | 255048 | Ferrari Grommet Shim - 255048 | $5.65 | Special order, ships in 7-14 days |
| 9 | 231618 | Ferrari Allen Head Screw M6x20 TCEI - 231618 | $0.57 | Available, ships in 3-6 days |
| 10 | 308995 | Ferrari Plug - 308995 | $4.39 | Special order, ships in 7-14 days |
| 11 | 264740 | Ferrari Plug 40x24mm - 264740 | $1.53 | Special order, ships in 7-14 days |
| 12 | 259642 | Ferrari Banjo Bolt Pipe Union - 259642 | $31.93 | Special order, ships in 7-14 days |
| 13 | 260155 | Ferrari Gasket D12- 18X1.5 - 260155 | $7.84 | Special order, ships in 7-14 days |
| 14 | 13432070 | Ferrari/Maserati Screw Collar / Hose Clamp - 13432070 | $0.95 | In stock |
| 15 | 55010260 | Ferrari Lift System Tank Shield - 55010260 | $218.81 | Special order, ships in 7-14 days |
| 16 | 943612 | Ferrari Lift System Oil Tank Mountin - 943612 | $71.28 | Special order, ships in 7-14 days |
| 17 | 13046112 | Ferrari Nut - 13046112 | $0.46 | Available, ships in 3-6 days |
| 18 | 257273 | Ferrari Clip D. 14-16 - 257273 | $2.59 | Special order, ships in 7-14 days |
| 19 | 817673 | Ferrari Lift System Pipe From Pump T - 817673 | $145.03 | Special order, ships in 7-14 days |
| 20 | 809256 | Ferrari Lift System Pipe From 3-Way - 809256 | $164.72 | Special order, ships in 7-14 days |
| 20 | 55026171 | Ferrari LIFT SYSTEM PIPE FROM 3-WAY UNION TO LH DISCONNECTOR UNION - 55026171 | Price on request | Contact us for price and availability |
| 21 | 763730 | Ferrari Lift System Pipe From Discon - 763730 | $159.79 | Special order, ships in 7-14 days |
| 21 | 763731 | Ferrari Lift System Pipe From Discon - 763731 | $159.79 | Special order, ships in 7-14 days |
| 22 | 292189 | Ferrari Lift System Distributor Block - 292189 | $169.62 | Special order, ships in 7-14 days |
| 23 | 763693 | Ferrari LH Front Bracket - 763693 | $49.14 | Special order, ships in 7-14 days |
| 23 | 763694 | Ferrari RH Front Bracket - 763694 | $49.14 | Special order, ships in 7-14 days |
| 24 | 116374 | Ferrari/Maserati Clip - 116374 | $3.20 | In stock |
| 25 | 256323 | Ferrari Screw 5x16 - 256323 | $0.98 | Available, ships in 3-6 days |
| 26 | 256962 | Ferrari Clip D. 4.7X1 - 256962 | $1.36 | Special order, ships in 7-14 days |
| 27 | 262737 | Ferrari Rubber Retainer - 262737 | $10.06 | Special order, ships in 7-14 days |
