Ferrari 12 Cilindri — [VEHICLE TRIM] - E.09 - FRONT LID SUBSTRUCTURE (diagram 0105)

Exploded view of the [vehicle trim] - e.09 - front lid substructure on the Ferrari 12 Cilindri, with 21 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 12 Cilindri [VEHICLE TRIM] - E.09 - FRONT LID SUBSTRUCTURE exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
10413870Ferrari Belleville Washer - 10413870SupersededOrder 12646724 instead
12601570Ferrari Washer - 12601570SupersededOrder 12646724 instead
12601571Ferrari Washer - 12601571SupersededOrder 12646724 instead
12643711Ferrari Washer - 12643711SupersededOrder 12643724 instead
12643721Ferrari Washer - 12643721SupersededOrder 12643724 instead
12646721Ferrari Washer - 12646721SupersededOrder 12646724 instead
14499301Ferrari Washer - 14499301SupersededOrder 12643724 instead
1985774520Ferrari Compl. Front Lid - 985774520$30,084.30Contact us to order
1985786839Ferrari Compl. Front Lid - 985786839$29,742.96Contact us to order
2774548Ferrari Cerniera Cofano Anteriore - 774548$1,180.21Contact us to order
3985774519Ferrari Compl. LH Clamshell Lid Cladding - 985774519$1,819.49Special order, ships in 7-14 days
3985774518Ferrari Compl. RH Clamshell Lid Cladding - 985774518$1,819.49Special order, ships in 7-14 days
4893581Ferrari Screw M8 x 25 - 893581$1.48Special order, ships in 7-14 days
512646724Ferrari Washer 8.45-20x2 - 12646724$0.19Available, ships in 3-6 days
6269959Ferrari Screw - 269959$1.61In stock
712643724Ferrari/Maserati Washer - 12643724$0.20In stock
8298365Ferrari Split Washer - 298365$14.62Special order, ships in 7-14 days
9977040Ferrari Washer - 977040$3.91Special order, ships in 7-14 days
1083743900Ferrari Screw M8 x 90 - 83743900$6.96Available, ships in 3-6 days
11242223Ferrari Spacer 0.5mm - 242223$4.98Special order, ships in 7-14 days
11980674Ferrari Spacer 0.5mm - 980674$7.84Special order, ships in 7-14 days

All 12 Cilindri diagrams
