Ferrari 12 Cilindri — [VEHICLE TRIM] - E.16 - REAR SHIELDS (diagram 0115)
Exploded view of the [vehicle trim] - e.16 - rear shields on the Ferrari 12 Cilindri, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri [VEHICLE TRIM] - E.16 - REAR SHIELDS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri/0115.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 55056725 | Ferrari Rear Subframe Flat Undertray - 55056725 | $1,549.03 | Contact us to order |
| 1 | 874147 | Ferrari Rear Subframe Flat Undertray - 874147 | $1,475.26 | Contact us to order |
| 2 | 971623 | Ferrari Screw - 971623 | $4.56 | Special order, ships in 7-14 days |
| 2 | 55042970 | Ferrari Vite Doppia Rondella Imp. M6 - 55042970 | $4.56 | Special order, ships in 7-14 days |
| 3 | 782611 | Ferrari RH Rear Dam - 782611 | Price on request | Contact us for price and availability |
| 4 | 782612 | Ferrari LH Rear Dam - 782612 | Price on request | Contact us for price and availability |
| 5 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 6 | 12643701 | Ferrari Flat Washer - 12643701 | $0.12 | Available, ships in 3-6 days |
| 6 | 14447078 | Ferrari Washer D. 5.5 - 15 x 1 - 14447078 | $0.54 | Special order, ships in 7-14 days |
| 7 | 55046083 | Ferrari RH Rear Dam Front Part - 55046083 | $181.93 | Special order, ships in 7-14 days |
| 8 | 55046084 | Ferrari RH Rear Dam Rear Part - 55046084 | $172.10 | Special order, ships in 7-14 days |
| 9 | 55046081 | Ferrari LH Rear Dam Front Part - 55046081 | $181.93 | Special order, ships in 7-14 days |
| 10 | 55046082 | Ferrari LH Rear Dam Rear Part - 55046082 | $172.10 | Special order, ships in 7-14 days |
