Ferrari 12 Cilindri — [VEHICLE TRIM] - E.42 - REAR ACTIVE AERO (diagram 0144)
Exploded view of the [vehicle trim] - e.42 - rear active aero on the Ferrari 12 Cilindri, with 31 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri [VEHICLE TRIM] - E.42 - REAR ACTIVE AERO exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri/0144.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14368371 | Ferrari Screw Clip - 14368371 | Superseded | Order 14188971 instead | |
| 1 | 55036570 | Ferrari Compl. Variable Geom. Wing Mechanism - 55036570 | $7,214.84 | Special order, ships in 7-14 days |
| 2 | 787720 | Ferrari Compl. LH Variable Geom. Wing Carrier - 787720 | $811.38 | Special order, ships in 7-14 days |
| 2 | 787714 | Ferrari Compl. RH Variable Geom. Wing Carrier - 787714 | $811.38 | Special order, ships in 7-14 days |
| 3 | 55014331 | Ferrari LH variable Geom. Wing Nolder - 55014331 | $4,016.04 | Special order, ships in 7-14 days |
| 3 | 55014333 | Ferrari LH variable Geom. Wing Nolder - 55014333 | $4,151.87 | Special order, ships in 7-14 days |
| 3 | 787721 | Ferrari LH variable Geom. Wing Nolder - 787721 | $2,433.03 | Special order, ships in 7-14 days |
| 3 | 956513 | Ferrari LH variable Geom. Wing Nolder - 956513 | $7,505.21 | Special order, ships in 7-14 days |
| 3 | 956516 | Ferrari LH variable Geom. Wing Nolder - 956516 | $7,868.19 | Special order, ships in 7-14 days |
| 3 | 55014335 | Ferrari RH variable Geom. Wing Nolder - 55014335 | $4,016.04 | Special order, ships in 7-14 days |
| 3 | 55014337 | Ferrari RH variable Geom. Wing Nolder - 55014337 | $4,151.87 | Special order, ships in 7-14 days |
| 3 | 787715 | Ferrari RH variable Geom. Wing Nolder - 787715 | $2,433.03 | Special order, ships in 7-14 days |
| 3 | 956511 | Ferrari RH variable Geom. Wing Nolder - 956511 | $7,505.21 | Special order, ships in 7-14 days |
| 3 | 956514 | Ferrari RH variable Geom. Wing Nolder - 956514 | Price on request | Contact us for price and availability |
| 4 | 55015585 | Ferrari COMPL. LH REAR WING - 55015585 | Price on request | Contact us for price and availability |
| 4 | 952909 | Ferrari Compl. LH Rear Wing - 952909 | $3,044.21 | Contact us to order |
| 4 | 55015588 | Ferrari COMPL. RH REAR WING - 55015588 | $2,248.03 | Contact us to order |
| 4 | 953033 | Ferrari Compl. RH Rear Wing - 953033 | $3,044.21 | Contact us to order |
| 5 | 55035458 | Ferrari SCREW - 55035458 | Price on request | Contact us for price and availability |
| 5 | 897538 | Ferrari Screw M6 x 18 - 897538 | $3.26 | Special order, ships in 7-14 days |
| 6 | 888382 | Ferrari Screw - 888382 | $39.31 | Special order, ships in 7-14 days |
| 7 | 14059118 | Ferrari Nut - 14059118 | $1.23 | Special order, ships in 7-14 days |
| 8 | 13577778 | Ferrari Washer - 13577778 | $0.57 | Special order, ships in 7-14 days |
| 9 | 85691900 | Ferrari Screw M5 x 8 TBFTX - 85691900 | $0.65 | Available, ships in 3-6 days |
| 10 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 11 | 12638524 | Ferrari Flat Washer 8.15x15x1.5 - 12638524 | $0.12 | Available, ships in 3-6 days |
| 12 | 13046112 | Ferrari Nut - 13046112 | $0.46 | Available, ships in 3-6 days |
| 13 | 14440021 | Ferrari Allen Screw - 14440021 | $1.05 | Special order, ships in 7-14 days |
| 14 | 975316 | Ferrari Bush Plate - 975316 | $6.75 | Special order, ships in 7-14 days |
| 15 | 14188971 | Ferrari Screw Clip - 14188971 | $9.07 | Special order, ships in 7-14 days |
| 16 | 970681 | Ferrari Adjuster Bush - 970681 | $16.14 | Special order, ships in 7-14 days |
