Ferrari 12 Cilindri — [VEHICLE TRIM] - E.48 - CENTRE TUNNEL AND CONSOLE (diagram 0158)

Exploded view of the [vehicle trim] - e.48 - centre tunnel and console on the Ferrari 12 Cilindri, with 68 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 12 Cilindri [VEHICLE TRIM] - E.48 - CENTRE TUNNEL AND CONSOLE exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
13046012Ferrari Nut - 13046012SupersededOrder 13046011 instead
106853Ferrari Spring Washer 10mm - 106853SupersededOrder 12601474 instead
10516873Ferrari Washer - 10516873SupersededOrder 12601474 instead
1833548Ferrari COMPL. CENTRE TUNNEL TRAY - 833548Price on requestContact us for price and availability
255001609Ferrari RH Lateral Shell - 55001609$3,163.65Special order, ships in 7-14 days
2833842Ferrari RH Lateral Shell - 833842$639.27Special order, ships in 7-14 days
2834413Ferrari RH Lateral Shell - 834413$2,962.25Special order, ships in 7-14 days
355001608Ferrari LH Lateral Shell - 55001608$3,163.65Special order, ships in 7-14 days
3833750Ferrari LH Lateral Shell - 833750$639.27Special order, ships in 7-14 days
3834384Ferrari LH Lateral Shell - 834384$2,962.25Special order, ships in 7-14 days
4833844Ferrari Compl. RH Fixing Plate - 833844$909.73Special order, ships in 7-14 days
4996897Ferrari Compl. RH Fixing Plate - 996897$5,570.95Special order, ships in 7-14 days
5833791Ferrari Compl. LH Ace Surround - 833791$909.73Special order, ships in 7-14 days
5996843Ferrari Compl. LH Fixing Plate - 996843$5,570.95Special order, ships in 7-14 days
655073856Ferrari COMPL. RH SIDE PANEL - 55073856Price on requestContact us for price and availability
655073859Ferrari COMPL. RH SIDE PANEL - 55073859Price on requestContact us for price and availability
755073855Ferrari COMPL. LH SIDE PANEL - 55073855$1,713.42Contact us to order
755073858Ferrari COMPL. LH SIDE PANEL - 55073858Price on requestContact us for price and availability
885692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
967278400Ferrari BRACKET - 67278400$21.60Special order, ships in 7-14 days
1085691900Ferrari Screw M5 x 8 TBFTX - 85691900$0.65Available, ships in 3-6 days
1185833900Ferrari Screw M5 x 16 TBFTX - 85833900$0.65Available, ships in 3-6 days
1265752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
13833852Ferrari Compl. F1 Control Panel - 833852$2,341.71Special order, ships in 7-14 days
14833352Ferrari RH Lower Surround - 833352$194.22Special order, ships in 7-14 days
15833376Ferrari LH Lower Surround - 833376$194.22Special order, ships in 7-14 days
16835458Ferrari Raymond Clip - 835458$0.82Special order, ships in 7-14 days
17833591Ferrari Compl. Hazard Unit - 833591$1,920.19Special order, ships in 7-14 days
17894260Ferrari Compl. Hazard Unit - 894260$1,253.96Special order, ships in 7-14 days
18831791Ferrari Compl. F1 Shift Gate - 831791$2,433.03Special order, ships in 7-14 days
18961265Ferrari Compl. F1 Shift Gate - 961265$2,444.74Special order, ships in 7-14 days
19914293Ferrari Allen Head Bolt M4X16 - 914293$1.11Special order, ships in 7-14 days
20791875Ferrari Key Holder - 791875$467.15Special order, ships in 7-14 days
2155027878Ferrari Front Compartment - 55027878$811.38Special order, ships in 7-14 days
2155027981Ferrari Front Compartment - 55027981$835.97Special order, ships in 7-14 days
22833378Ferrari FRONT COMPARTMENT MAT - 833378Price on requestContact us for price and availability
22833883Ferrari Front Compartment Mat - 833883$46.69Special order, ships in 7-14 days
23902819Ferrari Fondello Cup Holder - 902819$29.48Special order, ships in 7-14 days
2488765900Ferrari Ashtray - 88765900$467.15Special order, ships in 7-14 days
25832134Ferrari Armrest Storage Bin - 832134$393.38Special order, ships in 7-14 days
26832118Ferrari BRACKET - 832118Price on requestContact us for price and availability
27888382Ferrari Screw - 888382$39.31Special order, ships in 7-14 days
2813046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
2912643701Ferrari Flat Washer - 12643701$0.12Available, ships in 3-6 days
30832691Ferrari Tunnel Tray Mat - 832691$41.76Special order, ships in 7-14 days
3168700200Ferrari Fixing Clip - 68700200$10.68Special order, ships in 7-14 days
3282889700Ferrari Clip - 82889700$1.63Available, ships in 3-6 days
33935243Ferrari Screw TBFTX T20 M4 x 10 Nerinox - 935243$0.96Special order, ships in 7-14 days
3488822200Ferrari Screw 4 x 10 - 88822200$1.30Special order, ships in 7-14 days
35900073Ferrari Actuator - 900073$104.88Special order, ships in 7-14 days
36900074Ferrari Actuator - 900074$104.88Special order, ships in 7-14 days
37863180Ferrari Bush - 863180$5.44Special order, ships in 7-14 days
3814059214Ferrari Flanged Nut M6 - 14059214$0.38Available, ships in 3-6 days
3813046111Ferrari Nut 6x6 - 13046111$0.73Special order, ships in 7-14 days
39127497Ferrari Spring Washer 10mm - 127497$0.69In stock
40987885Ferrari Bracket - 987885$31.93Special order, ships in 7-14 days
41854642Ferrari Armrest Hinge - 854642$117.99Special order, ships in 7-14 days
42854632Ferrari Rear Backing Trim Of Front A - 854632$223.73Special order, ships in 7-14 days
43934927Ferrari Allen Head Bolt Countersunk M4X8 - 934927$1.74Special order, ships in 7-14 days
4485692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
45854774Ferrari Armrest Cap - 854774$46.69Special order, ships in 7-14 days
4655001617Ferrari Armrest Storage Bin Surround - 55001617$3,788.88Special order, ships in 7-14 days
46832160Ferrari Armrest Storage Bin Surround - 832160$663.86Special order, ships in 7-14 days
46833286Ferrari Armrest Storage Bin Surround - 833286$3,589.84Special order, ships in 7-14 days
4755034181Ferrari COMPL. FRONT LID - 55034181Price on requestContact us to order
4755034187Ferrari COMPL. FRONT LID - 55034187Price on requestContact us to order
4812637878Ferrari Washer - 12637878$0.19Available, ships in 3-6 days
