Ferrari 246 Dino GT Coupe & Spyder (From Ch 02132) — Air Conditioning & Other Parts (diagram 040)
Exploded view of the air conditioning & other parts on the Ferrari 246 Dino GT Coupe & Spyder (From Ch 02132), with 32 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/040.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 12789 | Ferrari 246 Damper Pulley A/C version - 12789 | $1,843.23 | Available, ships in 3-6 days |
| 2 | 26811 | Ferrari Pulley - 26811 | $612.51 | Special order, ships in 7-14 days |
| 3 | 300028 | Ferrari Bracket - 300028 | Price on request | Contact us for price and availability |
| 4 | 300031 | Ferrari Bracket - 300031 | Price on request | Contact us for price and availability |
| 5 | 300045 | Ferrari Alternator Pulley - 300045 | $325.37 | Available, ships in 3-6 days |
| 6 | 300064 | Ferrari 246 Alternator Belt - 300064 | $98.84 | In stock |
| 7 | 26833 | Ferrari Tube - 26833 | Price on request | Contact us for price and availability |
| 7 | 26838 | Ferrari Tube - 26838 | Price on request | Contact us for price and availability |
| 8 | 26824 | Ferrari Water Hose - 26824 | $53.30 | Available, ships in 3-6 days |
| 8 | 26837 | Ferrari Tube - 26837 | Superseded | Order 26824 instead |
| 8 | 26839 | Ferrari Tube - 26839 | Price on request | Contact us for price and availability |
| 9 | 26836 | Ferrari 246 Coolant Hose - 26836 | $129.80 | In stock |
| 10 | 240782 | Ferrari Bracket - 240782 | Price on request | Contact us for price and availability |
| 11 | 240792 | Ferrari 246Gt/S Top Oil Hose - 240792 | $886.42 | Available, ships in 3-6 days |
| 11 | 240767/K | Ferrari Oil Hose Set - 246 Aircon cars - 240767/K | Price on request | Special order, ships in 7-14 days |
| 12 | 240767 | Ferrari Oil Hose - 240767 | $382.97 | Available, ships in 3-6 days |
| 13 | 105947 | Ferrari Bolt - 105947 | $3.09 | Available, ships in 3-6 days |
| 14 | 127497 | Ferrari Spring Washer 10mm - 127497 | $0.69 | In stock |
| 14 | 10516871 | Ferrari Washer - 10516871 | Superseded | Order 127497 instead |
| 15 | 320349 | Ferrari Bracket - 320349 | $491.93 | Special order, ships in 7-14 days |
| 16 | 320350 | Ferrari Bolt - 320350 | $38.85 | Available, ships in 3-6 days |
| 17 | 95571 | Ferrari Gasket - 95571 | Price on request | Contact us for price and availability |
| 18 | 95589 | Ferrari Pipe - 95589 | Superseded | Order 103406 instead |
| 18 | 103406 | Ferrari Hose - 103406 | $27.13 | Available, ships in 3-6 days |
| 19 | 104114 | Ferrari Nyloc Nut M10 x 1.25 x 12 - 104114 | $0.73 | Available, ships in 3-6 days |
| 19 | 12575621 | Ferrari Nyloc Nut - 12575621 | Superseded | Order 102742 instead |
| 20 | 95570 | Ferrari Washer - 95570 | Price on request | Contact us for price and availability |
| 21 | 12643701 | Ferrari Flat Washer - 12643701 | $0.12 | Available, ships in 3-6 days |
| 22 | 300072 | Ferrari Alternator - 300072 | Price on request | Contact us for price and availability |
| 23 | 240773 | Ferrari Part Search Results - 240773 | Price on request | Contact us for price and availability |
| 12575625 | Ferrari Nyloc Nut - 12575625 | Superseded | Order 102742 instead | |
| 102742 | Ferrari Nyloc Nut M10x1.25x10 - 102742 | $0.79 | Available, ships in 3-6 days |
