Ferrari 246 Dino GT Coupe & Spyder (From Ch 02132) — Brake Hydraulic System (Variants For RHD Versions) (diagram 043)
Exploded view of the brake hydraulic system (variants for rhd versions) on the Ferrari 246 Dino GT Coupe & Spyder (From Ch 02132), with 57 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/043.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 661057 | Ferrari Brake Servo Dino - 661057 | $30.07 | Available, ships in 3-6 days |
| 1 | 661057/C | Ferrari 246 Brake Master Cylinder Only - 661057/C | $943.48 | Available, ships in 3-6 days |
| 2 | 660932 | Ferrari Brake Lever 246 - 660932 | $202.75 | Available, ships in 3-6 days |
| 3 | 100976 | Ferrari Brake Pedal Pad - 100976 | $20.85 | In stock |
| 4 | 660941 | Ferrari Spacer - 660941 | Price on request | Contact us for price and availability |
| 5 | 660938 | Ferrari Lever - 660938 | Price on request | Contact us for price and availability |
| 6 | 660972 | Ferrari Pin - 660972 | Price on request | Contact us for price and availability |
| 7 | 660956 | Ferrari Rose Bearing - 660956 | Price on request | Contact us for price and availability |
| 8 | 660955 | Ferrari Rose Bearing - 660955 | Price on request | Contact us for price and availability |
| 9 | 660942 | Ferrari Rod - 660942 | Price on request | Contact us for price and availability |
| 10 | 660975 | Ferrari Pin - 660975 | $195.50 | Available, ships in 3-6 days |
| 11 | 660945 | Ferrari Lever - 660945 | Price on request | Contact us for price and availability |
| 12 | 660724 | Ferrari Washer - 660724 | Price on request | Contact us for price and availability |
| 13 | 660727 | Ferrari Washer - 660727 | Price on request | Contact us for price and availability |
| 14 | 660725 | Ferrari Bush - 660725 | $134.67 | Available, ships in 3-6 days |
| 15 | 660946 | Ferrari 246 Lever - 660946 | $135.70 | In stock |
| 16 | 101305 | Ferrari/Maserati Pedal Spring - 101305 | $53.79 | In stock |
| 17 | 104030 | Ferrari/Maserati Nut - 104030 | $0.88 | In stock |
| 18 | 103180 | Ferrari Wavy Washer - 103180 | $0.06 | Available, ships in 3-6 days |
| 18 | 12601374 | Ferrari Wavy Washer 8mm - 12601374 | $3.12 | Available, ships in 3-6 days |
| 19 | 14238130 | Ferrari Bolt - 14238130 | $2.84 | Available, ships in 3-6 days |
| 20 | 13550401 | Ferrari Washer 10.2-20x2 - 13550401 | $0.31 | Available, ships in 3-6 days |
| 20 | 13550424 | Ferrari Washer - 13550424 | $0.31 | Available, ships in 3-6 days |
| 21 | 10734301 | Ferrari Split Pin 2X18 - 10734301 | $0.13 | Available, ships in 3-6 days |
| 22 | 95541 | Ferrari RH Thread Nut - 95541 | $0.31 | Available, ships in 3-6 days |
| 23 | 103157 | Ferrari LH Thread Nut - 103157 | Price on request | Contact us for price and availability |
| 24 | 101648 | Ferrari Nyloc Nut M16 x 1.5 x 10.5 - 101648 | $6.54 | Available, ships in 3-6 days |
| 25 | 95870320 | Ferrari Bush - 95870320 | $15.74 | Available, ships in 3-6 days |
| 26 | 101662 | Ferrari Nylon Nut - 101662 | Price on request | Contact us for price and availability |
| 27 | 12601174 | Ferrari Wavy Washer 5mm - 12601174 | $0.12 | Available, ships in 3-6 days |
| 27 | 12605270 | Ferrari Washer - 12605270 | Superseded | Order 12601174 instead |
| 28 | 10791211 | Ferrari Nut - 10791211 | $0.96 | Available, ships in 3-6 days |
| 29 | 101663 | Ferrari Brake Light Switch - 101663 | $42.85 | In stock |
| 29 | 4177124 | Ferrari Stop Switch - 4177124 | Superseded | Order 101663 instead |
| 30 | 660723 | Ferrari Pin - 660723 | $12.61 | Available, ships in 3-6 days |
| 32 | 10734208 | Ferrari Split Pin D. 2 x 12 - 10734208 | $0.06 | Available, ships in 3-6 days |
| 32 | 10734201 | Ferrari Split Pin - 10734201 | Superseded | Order 10734208 instead |
| 33 | 661058 | Ferrari Tank - 661058 | Superseded | Order 103168 instead |
| 34 | 660687 | Ferrari Bracket - 660687 | Price on request | Contact us for price and availability |
| 35 | 10902224 | Ferrari Screw M6 x 16 - 10902224 | $0.12 | Available, ships in 3-6 days |
| 35 | 95880303 | Ferrari Bolt - 95880303 | $0.11 | Available, ships in 3-6 days |
| 36 | 127494 | Ferrari Lock Washer - 127494 | $0.50 | In stock |
| 36 | 10516470 | Ferrari Washer 6 R 4 - 10516470 | Superseded | Order 127494 instead |
| 37 | 661088 | Ferrari Tube - 661088 | Price on request | Contact us for price and availability |
| 38 | 94951 | Ferrari Clip - 94951 | Price on request | Contact us for price and availability |
| 103168 | Ferrari Brake Fluid Reservoir - 103168 | $71.50 | In stock | |
| 124512 | Ferrari Brake Master Cylinder -124512 | $730.98 | In stock | |
| 10788711 | Ferrari Nut - 10788711 | $0.38 | Available, ships in 3-6 days | |
| 16104125 | Ferrari Nut - 16104125 | Superseded | Order 104030 instead | |
| 660523 | Ferrari Nut - 660523 | Price on request | Contact us for price and availability | |
| 4032794 | Ferrari Nylon Nut - 4032794 | $5.59 | Available, ships in 3-6 days | |
| 108820 | Ferrari Servo LHD - 108820 | Price on request | Contact us for price and availability | |
| 106850 | Ferrari Spring Washer 6mm - 106850 | Superseded | Order 127494 instead | |
| 660522 | Ferrari Switch Stop - 660522 | Superseded | Order 101663 instead | |
| 12605274 | Ferrari Washer - 12605274 | Superseded | Order 12601174 instead | |
| 660525 | Ferrari Washer - 660525 | Superseded | Order 12601174 instead | |
| 128944 | Ferrari Washer D10.2-20 - 128944 | $3.68 | Available, ships in 3-6 days |
