Ferrari 250 GT 2+2 (GTE) — Bonnet (diagram 205B)
Exploded view of the bonnet on the Ferrari 250 GT 2+2 (GTE), with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/205B.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 241-28-538-04 | Ferrari Hood Initial Opening Spring - 241-28-538-04 | Price on request | Contact us for price and availability |
| 2 | 241-28-552-00 | Ferrari Bonnet Support - 241-28-552-00 | Price on request | Contact us for price and availability |
| 3 | 241-28-570-00 | Ferrari Spring - 241-28-570-00 | Price on request | Contact us for price and availability |
| 4 | 241-28-606-00 | Ferrari Bonnet Insulation - 241-28-606-00 | Price on request | Contact us for price and availability |
| 5 | 241-28-760-00 | Ferrari Moulding - 241-28-760-00 | Price on request | Contact us for price and availability |
| 6 | 241-28-842-00 | Ferrari Front Moulding - 241-28-842-00 | Price on request | Contact us for price and availability |
| 7 | 241-28-844-00 | Ferrari Rear Moulding - 241-28-844-00 | Price on request | Contact us for price and availability |
