Ferrari 250 GT 2+2 (GTE) — Doors (diagram 207B)
Exploded view of the doors on the Ferrari 250 GT 2+2 (GTE), with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/207B.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 241-30-172-00 | Ferrari RH Door Lock Mech - 241-30-172-00 | Price on request | Contact us for price and availability |
| 2 | 241-30-173-00 | Ferrari LH Door Lock Mech - 241-30-173-00 | Price on request | Contact us for price and availability |
| 3 | 241-30-210-00 | Ferrari LH Door Lock Catch Plate - 241-30-210-00 | Price on request | Contact us for price and availability |
| 4 | 241-30-211-11 | Ferrari RH Door Lock Catch Plate - 241-30-211-11 | Price on request | Contact us for price and availability |
| 5 | 241-30-216-00 | Ferrari Door Catch Spacer - 241-30-216-00 | $13.52 | Available, ships in 3-6 days |
| 6 | 241-30-240-00 | Ferrari RH Door Catch Lock Buffer - 241-30-240-00 | Price on request | Contact us for price and availability |
| 7 | 241-30-241-00 | Ferrari LH Door Catch Lock Buffer - 241-30-241-00 | Price on request | Contact us for price and availability |
| 8 | 239-30-266-08 | Ferrari RH Plate - 239-30-266-08 | Price on request | Contact us for price and availability |
| 9 | 239-30-267-08 | Ferrari LH Plate - 239-30-267-08 | Price on request | Contact us for price and availability |
| 10 | 239-30-274-00 | Ferrari Plastic Tube - 239-30-274-00 | Price on request | Contact us for price and availability |
| 11 | 239-30-282-00 | Ferrari RH Handle Rubber Gasket - 239-30-282-00 | Price on request | Contact us for price and availability |
| 12 | 239-30-283-00 | Ferrari LH Handle Rubber Gasket - 239-30-283-00 | Price on request | Contact us for price and availability |
