Ferrari 250 GT 2+2 (GTE) — Doors (diagram 207F)
Exploded view of the doors on the Ferrari 250 GT 2+2 (GTE), with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/207F.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 241-30-700-00 | Ferrari RH Front Armrest Complete - 241-30-700-00 | Price on request | Contact us for price and availability |
| 2 | 241-30-701-00 | Ferrari LH Front Armrest Complete - 241-30-701-00 | Price on request | Contact us for price and availability |
| 3 | 242-80-832-00 | Ferrari Door Light Switch - 242-80-832-00 | $137.30 | Available, ships in 3-6 days |
| 3 | 239-30-830-00 | Ferrari Door Light Switch - 239-30-830-00 | $137.30 | Available, ships in 3-6 days |
| 4 | 241-30-810-00 | Ferrari RH Interior Door Handle - 241-30-810-00 | $89.86 | Available, ships in 3-6 days |
| 5 | 241-30-811-00 | Ferrari LH Interior Door Handle - 241-30-811-00 | $40.23 | Special order, ships in 7-14 days |
| 6 | 241-30-830-00 | Ferrari Ring - 241-30-830-00 | Price on request | Contact us for price and availability |
| 7 | 239-30-850-00 | Ferrari Window Winder Handle - 239-30-850-00 | $314.17 | Special order, ships in 7-14 days |
| 8 | 241-30-852-00 | Ferrari Washer For Door Handle - 241-30-852-00 | Price on request | Contact us for price and availability |
| 9 | 239-30-854-00 | Ferrari Ring - 239-30-854-00 | Price on request | Contact us for price and availability |
| 10 | 239-30-856-00 | Ferrari Spring - 239-30-856-00 | Price on request | Contact us for price and availability |
| 11 | 241-30-870-00 | Ferrari Knob - 241-30-870-00 | Price on request | Contact us for price and availability |
| 12 | 241-30-674-00 | Ferrari RH Panel - 241-30-674-00 | Price on request | Contact us for price and availability |
