Ferrari 250 GT 2+2 (GTE) — Doors (diagram 207H)
Exploded view of the doors on the Ferrari 250 GT 2+2 (GTE), with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/207H.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 241-30-880-00 | Ferrari Window Winder - 241-30-880-00 | Price on request | Contact us for price and availability |
| 2 | 241-30-900-00 | Ferrari RH Door Moulding - 241-30-900-00 | Price on request | Contact us for price and availability |
| 3 | 241-30-901-00 | Ferrari LH Door Moulding - 241-30-901-00 | Price on request | Contact us for price and availability |
| 4 | 241-30-910-00 | Ferrari Window Rubber - 241-30-910-00 | Price on request | Contact us for price and availability |
| 5 | 241-30-916-00 | Ferrari RH Moulding - 241-30-916-00 | Price on request | Contact us for price and availability |
| 6 | 241-30-917-00 | Ferrari LH Moulding - 241-30-917-00 | Price on request | Contact us for price and availability |
| 7 | 241-30-920-00 | Ferrari Window Rubber - 241-30-920-00 | Price on request | Contact us for price and availability |
| 8 | 241-30-928-00 | Ferrari RH Door Finish - 241-30-928-00 | Price on request | Contact us for price and availability |
| 9 | 241-30-929-00 | Ferrari LH Door Finish - 241-30-929-00 | Price on request | Contact us for price and availability |
| 10 | 241-30-934-00 | Ferrari RH Door Finish - 241-30-934-00 | Price on request | Contact us for price and availability |
| 11 | 241-30-935-00 | Ferrari LH Door Finish - 241-30-935-00 | Price on request | Contact us for price and availability |
| 12 | 241-30-960-00 | Ferrari RH Door Check Strap - 241-30-960-00 | Price on request | Contact us for price and availability |
