Ferrari 250 GT 2+2 (GTE) — Rear Bumpers (diagram 211A)
Exploded view of the rear bumpers on the Ferrari 250 GT 2+2 (GTE), with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/211A.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 241-36-500-00 | Ferrari Rear Bumper Complete Assy NOT CHROMED - 241-36-500-00 | Price on request | Contact us for price and availability |
| 2 | 241-36-502-00 | Ferrari Bumper Less Over Riders - 241-36-502-00 | $389.16 | Available, ships in 3-6 days |
| 3 | 241-36-504-00 | Ferrari Rear Bumper - 241-36-504-00 | Price on request | Contact us to order |
| 4 | 241-36-510-00 | Ferrari RH Rear Qtr Bumper - 241-36-510-00 | $145.21 | Available, ships in 3-6 days |
| 5 | 241-36-511-00 | Ferrari LH Rear Qtr Bumper - 241-36-511-00 | Price on request | Contact us for price and availability |
| 6 | 241-36-602-00 | Ferrari RH Rear Bumper Iron - 241-36-602-00 | $61.33 | Special order, ships in 7-14 days |
| 7 | 241-36-603-00 | Ferrari LH Rear Bumper Iron - 241-36-603-00 | Price on request | Contact us for price and availability |
| 8 | 241-36-860-00 | Ferrari RH Rear Over Rider - 241-36-860-00 | Price on request | Contact us for price and availability |
| 9 | 241-36-861-00 | Ferrari LH Rear Over Rider - 241-36-861-00 | Price on request | Contact us for price and availability |
| 10 | 241-36-752-00 | Ferrari RH Rear Bumper Iron Cover - 241-36-752-00 | $83.58 | Available, ships in 3-6 days |
| 11 | 241-36-753-00 | Ferrari LH Rear Bumper Iron Cover - 241-36-753-00 | $83.58 | Available, ships in 3-6 days |
| 12 | 239-36-920-00 | Ferrari Rear Over-Rider Insert - 239-36-920-00 | $150.74 | Special order, ships in 7-14 days |
