Ferrari 250 GT 2+2 (GTE) — System Electrics (diagram 223A)
Exploded view of the system electrics on the Ferrari 250 GT 2+2 (GTE), with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/223A.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 241-80-150-00 | Ferrari Electrical Control Box LHD - 241-80-150-00 | Price on request | Contact us for price and availability |
| 2 | 241-80-151-00 | Ferrari Electrical Control Box RHD - 241-80-151-00 | Price on request | Contact us for price and availability |
| 3 | 241-80-346-00 | Ferrari Cover - 241-80-346-00 | Price on request | Contact us for price and availability |
| 4 | 239-80-348-02 | Ferrari Nut - 239-80-348-02 | Price on request | Contact us for price and availability |
| 5 | 239-80-654-00 | Ferrari 6-Way Rubber Connector - 239-80-654-00 | Price on request | Contact us for price and availability |
| 6 | 239-80-672-00 | Ferrari 5-Way Electrical Connector - 239-80-672-00 | Price on request | Contact us for price and availability |
| 7 | 239-80-802-00 | Ferrari Bulb Holder - 239-80-802-00 | Price on request | Contact us for price and availability |
| 8 | 239-34-830-00 | Ferrari Switch - 239-34-830-00 | Price on request | Contact us for price and availability |
| 10 | 241-80-816-02 | Ferrari Courtesy Light Switch - 241-80-816-02 | Price on request | Contact us for price and availability |
| 11 | 241-80-830-00 | Ferrari Roof Light - 241-80-830-00 | Price on request | Contact us for price and availability |
| 12 | 241-80-874-00 | Ferrari Single Switch for defroster - 241-80-874-00 | Price on request | Contact us for price and availability |
