Ferrari 250 GT 2+2 (GTE) — Front And Rear Lights (diagram 224A)
Exploded view of the front and rear lights on the Ferrari 250 GT 2+2 (GTE), with 15 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/224A.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 241-82-030-01 | Ferrari Head Lamp Rim - 241-82-030-01 | $72.29 | Special order, ships in 7-14 days |
| 2 | 239-82-100-00 | Ferrari Head Lamp Gasket - 239-82-100-00 | Price on request | Contact us for price and availability |
| 3 | 239-82-170-00 | Ferrari Front Sidelight Complete - 239-82-170-00 | $232.16 | Available, ships in 3-6 days |
| 4 | 239-82-160-00 | Ferrari Front Sidelight Lens - 239-82-160-00 | $77.04 | Available, ships in 3-6 days |
| 4 | 241-82-341-00 | Ferrari Indicator Lens Amber/Orange - 241-82-341-00 | $77.04 | Available, ships in 3-6 days |
| 5 | 241-82-350-00 | Ferrari Rear Lamp USA Lens - 241-82-350-00 | $894.15 | Available, ships in 3-6 days |
| 5 | 241-82-350-00/U | Ferrari Rear Lamp Lens - USA - 241-82-350-00/U | $906.22 | Available, ships in 3-6 days |
| 6 | 241-82-030-10 | Ferrari Front Light Surround - 241-82-030-10 | Price on request | Contact us for price and availability |
| 7 | 241-82-100-10 | Ferrari Head Lamp Rubber Gasket - 241-82-100-10 | Price on request | Contact us for price and availability |
| 8 | 241-74-590-00 | Ferrari Number Plate Frame Plastic Trim Set - 241-74-590-00 | $72.46 | Special order, ships in 7-14 days |
| 9 | 241-82-198-00 | Ferrari Front Sidelamp Chrome Ring - 241-82-198-00 | Price on request | Contact us for price and availability |
| 10 | 241-82-334-00 | Ferrari 250GTE Tail Lamp Gasket - Series 1 - 241-82-334-00 | $38.93 | Available, ships in 3-6 days |
| 11 | 241-82-340-01 | Ferrari Rear Light Lens- Amber/Red Version - 241-82-340-01 | $346.73 | Available, ships in 3-6 days |
| 12 | 241-82-342-10 | Ferrari Lamp Assy Rear - 241-82-342-10 | $281.23 | Available, ships in 3-6 days |
| 12 | 241-82-342-10/A | Ferrari Rear Lamp - Body Only - 241-82-342-10/A | $285.03 | Available, ships in 3-6 days |
