Ferrari 250 GT 2+2 (GTE) — Front And Rear Lights (diagram 224B)
Exploded view of the front and rear lights on the Ferrari 250 GT 2+2 (GTE), with 14 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/224B.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 241-82-350-00 | Ferrari Rear Lamp USA Lens - 241-82-350-00 | $894.15 | Available, ships in 3-6 days |
| 1 | 241-82-350-00/U | Ferrari Rear Lamp Lens - USA - 241-82-350-00/U | $906.22 | Available, ships in 3-6 days |
| 2 | 241-82-400-00 | Ferrari Rear Reflector - 241-82-400-00 | $75.71 | Available, ships in 3-6 days |
| 3 | 241-82-490-00 | Ferrari Lamp Lens - 241-82-490-00 | $39.95 | Special order, ships in 7-14 days |
| 4 | 241-82-340-00 | Ferrari Tail Lamp Round Lens Red - 241-82-340-00 | $297.10 | Available, ships in 3-6 days |
| 4 | 241-82-340-00/A | Ferrari Tail Lamp Round Lens Red (Buy in pairs) - 241-82-340-00/A | $301.11 | Available, ships in 3-6 days |
| 5 | 241-82-342-10 | Ferrari Lamp Assy Rear - 241-82-342-10 | $281.23 | Available, ships in 3-6 days |
| 5 | 241-82-342-10/A | Ferrari Rear Lamp - Body Only - 241-82-342-10/A | $285.03 | Available, ships in 3-6 days |
| 6 | 241-82-450-00 | Ferrari Number Plate Light Holder - 241-82-450-00 | Price on request | Contact us for price and availability |
| 7 | 241-82-440-00 | Ferrari Rear Number Plate Lamp Lens - 241-82-440-00 | Price on request | Contact us for price and availability |
| 8 | 241-82-202-00 | Ferrari Repeater Lamp - 241-82-202-00 | $185.71 | Available, ships in 3-6 days |
| 8 | 20404000/U | Ferrari Front Side Lamp Assembly - 20404000/U | $673.40 | Available, ships in 3-6 days |
| 9 | 241-82-210-00 | Ferrari Repeater Lamp - 241-82-210-00 | Price on request | Contact us for price and availability |
| 10 | 241-82-480-02 | Ferrari Reverse Light - 241-82-480-02 | Price on request | Contact us for price and availability |
