Ferrari 275 GTS — Windscreen Wipers (diagram 225)
Exploded view of the windscreen wipers on the Ferrari 275 GTS, with 23 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 243-84-010-00 | Ferrari Wiper Motor Unit Complete LHD - 243-84-010-00 | Price on request | Contact us for price and availability |
| 1 | 243-84-012-00 | Ferrari Wiper Motor - 243-84-012-00 | Price on request | Contact us for price and availability |
| 1 | 247-84-010-00 | Ferrari Wiper Motor Unit Complete RHD - 247-84-010-00 | Price on request | Contact us for price and availability |
| 1A | 243-84-010-10 | Ferrari Wiper Motor Unit Complete LHD - 243-84-010-10 | Price on request | Contact us for price and availability |
| 1A | 247-84-010-10 | Ferrari Wiper Motor Unit Complete RHD - 247-84-010-10 | Price on request | Contact us for price and availability |
| 1A | 243-84-012-10 | Ferrari Wiper Motor - 243-84-012-10 | Price on request | Contact us for price and availability |
| 2 | 241-84-070-00 | Ferrari Turret - 241-84-070-00 | Price on request | Contact us for price and availability |
| 3 | 239-84-110-00 | Ferrari Wiper Arm Pivot Bush - 239-84-110-00 | $84.77 | Available, ships in 3-6 days |
| 4 | 242-84-112-08 | Ferrari Nut for Wiper Pivot - 242-84-112-08 | Price on request | Contact us for price and availability |
| 5 | 243-84-170-01 | Ferrari Tube - 243-84-170-01 | Price on request | Contact us for price and availability |
| 5A | 243-84-170-11 | Ferrari Tube - 243-84-170-11 | Price on request | Contact us for price and availability |
| 6 | 243-84-180-01 | Ferrari Bowden Tube Between Wiper Arms - 243-84-180-01 | Price on request | Contact us for price and availability |
| 6A | 243-84-180-11 | Ferrari Tube - 243-84-180-11 | Price on request | Contact us for price and availability |
| 7 | 241-84-190-01 | Ferrari Short Tube - 241-84-190-01 | Price on request | Contact us for price and availability |
| 8 | 242-84-250-02 | Ferrari Wiper Arm - 242-84-250-02 | $143.93 | In stock |
| 8A | 243-84-250-02 | Ferrari Wiper Arm LHD - 243-84-250-02 | $103.49 | Available, ships in 3-6 days |
| 8A | MC3800/11 | Ferrari Wiper Arm 275GTB/4 - MC3800/11 | Price on request | Special order, ships in 7-14 days |
| 8B | 243-84-250-12 | Ferrari Wiper Arm LHD - 243-84-250-12 | Price on request | Contact us for price and availability |
| 8B | 247-84-250-12 | Ferrari Wiper Arm RHD - 247-84-250-12 | $103.49 | Available, ships in 3-6 days |
| 9 | 241-84-280-02 | Ferrari Wiper Blade - 241-84-280-02 | Price on request | Contact us for price and availability |
| 9A | 243-84-280-02 | Ferrari Wiper Blade LHD - 243-84-280-02 | Price on request | Contact us for price and availability |
| 9B | 243-84-280-12 | Ferrari Wiper Blade RHD - 243-84-280-12 | Price on request | Contact us for price and availability |
| 10 | 242-84-528-06 | Ferrari Wiper Linkage Bracket - 242-84-528-06 | Price on request | Contact us for price and availability |
