Ferrari 296 GTB — [VEHICLE TRIM] - E.18 - REAR WHEELHOUSE (diagram 0117)
Exploded view of the [vehicle trim] - e.18 - rear wheelhouse on the Ferrari 296 GTB, with 19 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTB [VEHICLE TRIM] - E.18 - REAR WHEELHOUSE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gtb/0117.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 881061 | Ferrari Screw M6x18 with Washer - 881061 | Superseded | Order 936581 instead | |
| 1 | 858966 | Ferrari Compl. RH Rear Wheel House - 858966 | $524.51 | Special order, ships in 7-14 days |
| 1 | 980571 | Ferrari Compl. RH Rear WheeLHouse - 980571 | Superseded | Order 858966 instead |
| 1 | 861572 | Ferrari RH Rear WheeLHouse - 861572 | $371.53 | Special order, ships in 7-14 days |
| 1 | 865629 | Ferrari RH Rear WheeLHouse - 865629 | $524.51 | Special order, ships in 7-14 days |
| 2 | 55042512 | Ferrari Compl. LH Rear Wheel House - 55042512 | $633.80 | Special order, ships in 7-14 days |
| 2 | 858384 | Ferrari Compl. LH Rear Wheel House - 858384 | $633.80 | Special order, ships in 7-14 days |
| 2 | 980570 | Ferrari Compl. LH Rear WheeLHouse - 980570 | Price on request | Contact us for price and availability |
| 2 | 55042513 | Ferrari LH Rear WheeLHouse - 55042513 | Superseded | Order 865618 instead |
| 2 | 861571 | Ferrari LH Rear WheeLHouse - 861571 | $371.53 | Special order, ships in 7-14 days |
| 2 | 865618 | Ferrari LH Rear WheeLHouse - 865618 | $524.51 | Special order, ships in 7-14 days |
| 3 | 783923 | Ferrari Compl. RH Lower Bracket Fast - 783923 | $86.04 | Special order, ships in 7-14 days |
| 4 | 783929 | Ferrari Compl. LH Lower Bracket Fast - 783929 | $83.57 | Special order, ships in 7-14 days |
| 5 | 980567 | Ferrari Compl. RH Upper Bracket Fast - 980567 | $61.45 | Special order, ships in 7-14 days |
| 6 | 980568 | Ferrari Compl. LH Upper Bracket Fast - 980568 | $76.19 | Special order, ships in 7-14 days |
| 7 | 808553 | Ferrari Stud Bolt - 808553 | $17.42 | Special order, ships in 7-14 days |
| 8 | 936581 | Ferrari M6x18 Screw With Captive Washer - 936581 | $1.34 | Special order, ships in 7-14 days |
| 9 | 87546600 | Ferrari Clip - 87546600 | $1.74 | Available, ships in 3-6 days |
| 10 | 83222200 | Ferrari Fastener Button - 83222200 | $1.42 | Available, ships in 3-6 days |
