Ferrari 296 GTB — [VEHICLE TRIM] - E.29.03 - DOORS - WINDOW AND WINDOW LIFTER (diagram 0130)
Exploded view of the [vehicle trim] - e.29.03 - doors - window and window lifter on the Ferrari 296 GTB, with 8 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTB [VEHICLE TRIM] - E.29.03 - DOORS - WINDOW AND WINDOW LIFTER exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gtb/0130.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 967219 | Ferrari LH Front Door Window Lifter - 967219 | $1,223.91 | Special order, ships in 7-14 days |
| 1 | 967211 | Ferrari RH Front Door Window Lifter - 967211 | $1,223.91 | Special order, ships in 7-14 days |
| 2 | 14059311 | Ferrari NUT - 14059311 | $0.52 | Available, ships in 3-6 days |
| 3 | 911723 | Ferrari Cristallo Porta Sx - 911723 | $305.96 | Contact us to order |
| 3 | 911894 | Ferrari RH Door Window - 911894 | $327.81 | Contact us to order |
| 4 | 920477 | Ferrari LH Door Triangle Trim - 920477 | $368.79 | Special order, ships in 7-14 days |
| 4 | 920478 | Ferrari RH Door Triangle Trim - 920478 | $368.79 | Special order, ships in 7-14 days |
| 5 | 46401657 | Ferrari Screw TBEI M6 x 12 Torx - 46401657 | $1.04 | Available, ships in 3-6 days |
