Ferrari 296 GTB — [VEHICLE TRIM] - E.39 - REAR LID OPENING MECHANISM (diagram 0140)
Exploded view of the [vehicle trim] - e.39 - rear lid opening mechanism on the Ferrari 296 GTB, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTB [VEHICLE TRIM] - E.39 - REAR LID OPENING MECHANISM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gtb/0140.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 902165 | Ferrari Engine Compartment Lid Relea - 902165 | Superseded | Order 940323 instead |
| 1 | 903460 | Ferrari Engine Compartment Lid Relea - 903460 | Superseded | Order 940323 instead |
| 1 | 940323 | Ferrari Engine Compartment Lid Relea - 940323 | $614.67 | Special order, ships in 7-14 days |
| 1 | 902166 | Ferrari Maniglia Apertura Cofano Mot - 902166 | Superseded | Order 940320 instead |
| 1 | 940320 | Ferrari Maniglia Apertura Cofano Mot - 940320 | $590.08 | Special order, ships in 7-14 days |
| 1 | 985397 | Ferrari Maniglia Apertura Cofano Mot - 985397 | Superseded | Order 940320 instead |
| 2 | 64215300 | Ferrari Door Rod Clip - 64215300 | $0.82 | Available, ships in 3-6 days |
| 3 | 849815 | Ferrari Anti Vibration Damper - 849815 | $51.62 | Available, ships in 3-6 days |
| 4 | 14569680 | Ferrari Clip - 14569680 | $0.13 | Special order, ships in 7-14 days |
| 4 | 14569880 | Ferrari Clip 14.5x3 - 14569880 | $0.65 | Special order, ships in 7-14 days |
| 5 | 10441290 | Ferrari P Clip Bracket With Sheath 28mm D.10 - 10441290 | $1.02 | Available, ships in 3-6 days |
| 6 | 16281827 | Ferrari Screw 5x14 - 16281827 | $0.46 | Special order, ships in 7-14 days |
| 7 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
