Ferrari 296 GTB — [VEHICLE TRIM] - E.47.03 - DASHBOARD - TRIM -Not for RHD- (diagram 0151)

Exploded view of the [vehicle trim] - e.47.03 - dashboard - trim -not for rhd- on the Ferrari 296 GTB, with 57 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 296 GTB [VEHICLE TRIM] - E.47.03 - DASHBOARD - TRIM -Not for RHD- exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
1801041Ferrari Compl. Lower Steering Column - 801041$614.67Special order, ships in 7-14 days
1801077Ferrari Compl. Lower Steering Column - 801077$442.56Special order, ships in 7-14 days
1801103Ferrari Compl. Lower Steering Column - 801103$393.38Special order, ships in 7-14 days
1970282Ferrari Compl. Lower Steering Column - 970282$295.03Special order, ships in 7-14 days
2970293Ferrari Upper Steering Column Shield - 970293$204.05Special order, ships in 7-14 days
584001400Ferrari Joystick Panel - 84001400$120.46Special order, ships in 7-14 days
6741790Ferrari Complete Cluster Bracket - 741790$130.29Special order, ships in 7-14 days
870007700Ferrari CLUSTER MOUNTING PANEL - 70007700Price on requestContact us for price and availability
8743775Ferrari Cluster Mounting Panel - 743775$4,542.92Special order, ships in 7-14 days
8970151Ferrari CLUSTER MOUNTING PANEL - 970151Price on requestContact us for price and availability
970007701Ferrari COMPL. BROW - 70007701Price on requestContact us for price and availability
9970161Ferrari Compl. Brow - 970161$467.15Special order, ships in 7-14 days
9743860Ferrari Palpebra Carbonio Cpl - 743860$5,044.06Special order, ships in 7-14 days
1070007702Ferrari UPPER CLUSTER SHELL - 70007702Price on requestContact us for price and availability
10743892Ferrari Upper Cluster Shell - 743892$3,435.29Special order, ships in 7-14 days
10970212Ferrari Upper Cluster Shell - 970212$142.58Special order, ships in 7-14 days
11970197Ferrari Compl. Centre Speaker Surrou - 970197$221.26Special order, ships in 7-14 days
12970205Ferrari Compl. Diffuser Surround - 970205$786.79Special order, ships in 7-14 days
13985406Ferrari Rete Isolam. Microf. Gsm Sin - 985406$28.39Special order, ships in 7-14 days
14970199Ferrari RH Speaker Surround - 970199Price on requestContact us for price and availability
15970148Ferrari LH Speaker Surround - 970148Price on requestContact us for price and availability
16852490Ferrari Compl. Cover Bag - 852490$12,024.75Contact us to order
16914061Ferrari Compl. Cover Bag - 914061$12,301.08Contact us to order
1770007703Ferrari COMP. RH LATERAL VENT BEZEL - 70007703Price on requestContact us for price and availability
17743784Ferrari Comp. RH Lateral Vent Bezel - 743784$2,899.04Special order, ships in 7-14 days
17970225Ferrari Compl. RH Lateral Casting - 970225$811.38Special order, ships in 7-14 days
18970245Ferrari Compl. RH Cluster Casting - 970245$1,450.67Special order, ships in 7-14 days
1870007704Ferrari COMPL. RH CLUSTER TRIM - 70007704Price on requestContact us for price and availability
18743786Ferrari Compl. RH Cluster Trim - 743786$5,004.25Special order, ships in 7-14 days
19970252Ferrari Compl. LH Cluster Casting - 970252$1,475.26Special order, ships in 7-14 days
1970007705Ferrari COMPL. LH CLUSTER TRIM - 70007705Price on requestContact us for price and availability
19743776Ferrari Compl. LH Cluster Trim - 743776$5,446.84Special order, ships in 7-14 days
20969295Ferrari RH Vent - 969295$368.79Special order, ships in 7-14 days
21969292Ferrari LH Vent - 969292$368.79Special order, ships in 7-14 days
22770756Ferrari Compl. Display Mount - 770756$6,854.22Special order, ships in 7-14 days
22832060Ferrari Compl. Display Mount - 832060$6,720.73Special order, ships in 7-14 days
22970343Ferrari Compl. Display Mount - 970343$983.50Special order, ships in 7-14 days
23969312Ferrari Centre Vent - 969312$442.56Special order, ships in 7-14 days
2465752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
26914184Ferrari RH Lateral Display Bracket - 914184$18.90Special order, ships in 7-14 days
27947658Ferrari Centre Underdashboard Elemen - 947658$5,231.39Special order, ships in 7-14 days
27947660Ferrari Centre Underdashboard Elemen - 947660Price on requestContact us for price and availability
28947661Ferrari Compl. RH Lower Plug - 947661$540.90Special order, ships in 7-14 days
28947662Ferrari Compl. RH Lower Plug - 947662$663.86Special order, ships in 7-14 days
29947663Ferrari Compl. LH Lower Plug - 947663$2,415.11Special order, ships in 7-14 days
29947664Ferrari COMPL. LH LOWER PLUG - 947664Price on requestContact us for price and availability
29947666Ferrari Compl. LH Lower Plug - 947666$786.79Special order, ships in 7-14 days
29947667Ferrari Compl. LH Lower Plug - 947667$3,058.27Special order, ships in 7-14 days
30970294Ferrari Compl. RH Satellite Plug - 970294$10.81Special order, ships in 7-14 days
31947668Ferrari Compl. LH Satellite Plug - 947668$417.97Special order, ships in 7-14 days
32890157Ferrari Grub Screw - 890157$2.82Special order, ships in 7-14 days
33793413Ferrari Dashboard Badge - 793413$319.62Special order, ships in 7-14 days
3487511200Ferrari Screw - 87511200$0.79Special order, ships in 7-14 days
35808368Ferrari Vics Antenna Base - 808368$98.32Special order, ships in 7-14 days
36808364Ferrari 5.8 Ghz Antenna Base - 808364$73.73Special order, ships in 7-14 days
37888781Ferrari Compl. Sun Visor - 888781$1,008.09Special order, ships in 7-14 days
37888782Ferrari Compl. Sun Visor - 888782$5,135.39Special order, ships in 7-14 days
