Ferrari 296 GTB — [ELECTRICAL SYSTEM] - F.06 - ELECTRICAL SYSTEM CONTROL UNITS (diagram 0181)

Exploded view of the [electrical system] - f.06 - electrical system control units on the Ferrari 296 GTB, with 46 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 296 GTB [ELECTRICAL SYSTEM] - F.06 - ELECTRICAL SYSTEM CONTROL UNITS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
967340Ferrari Centralina Epc Can500 M - 967340SupersededOrder 773542 instead
967341Ferrari Centralina Epc Can500 S - 967341SupersededOrder 773543 instead
14039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
1938639Ferrari Parking Sensor ECU - 938639$417.97Special order, ships in 7-14 days
2764604Ferrari Hvac Ecu - 764604$1,844.08Special order, ships in 7-14 days
385834000Ferrari Screw M5 x 25 - 85834000$0.71Special order, ships in 7-14 days
4811458Ferrari Active Aero Control Unit - 811458$2,013.87Special order, ships in 7-14 days
5959875Ferrari Active Aero ECU Mounting Bra - 959875$58.98Special order, ships in 7-14 days
5875043Ferrari Suspension ECU Mounting Brac - 875043$66.35Special order, ships in 7-14 days
685692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
714059111Ferrari Flanged Nut M5 - 14059111$0.08Available, ships in 3-6 days
714039511Ferrari Nut - 14039511$0.54Available, ships in 3-6 days
855003062Ferrari Head Up Display - 55003062$5,460.89Special order, ships in 7-14 days
855003063Ferrari Head Up Display - 55003063$5,460.89Special order, ships in 7-14 days
8825027Ferrari Head Up Display - 825027$5,507.72Special order, ships in 7-14 days
8825029Ferrari Head Up Display - 825029SupersededOrder 942922 instead
8942921Ferrari Head Up Display - 942921$5,507.72Special order, ships in 7-14 days
8942922Ferrari Head Up Display - 942922$5,507.72Special order, ships in 7-14 days
9883403Ferrari Fixing and Centering Screw - 883403$28.39Special order, ships in 7-14 days
10804763Ferrari Airbag Ecu - 804763$1,008.09Special order, ships in 7-14 days
10835055Ferrari Airbag Ecu - 835055$1,081.84Special order, ships in 7-14 days
10971724Ferrari Airbag ECU - 971724$1,008.09Special order, ships in 7-14 days
11979058Ferrari Airbag ECU Bracket - 979058$83.57Special order, ships in 7-14 days
12294780Ferrari Allen Head Bolt with Washer M5X16 - 294780$0.98Special order, ships in 7-14 days
13786545Ferrari Body Computer - 786545$1,475.26Special order, ships in 7-14 days
1416286127Ferrari Screw 6x20 - 16286127$0.82Available, ships in 3-6 days
1485692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
15829517Ferrari Matrix Headlamp ECU - 829517$491.74Special order, ships in 7-14 days
16778365Ferrari Matrix Headlamp ECU Bracket - 778365$142.58Special order, ships in 7-14 days
17934044Ferrari Variable Geometry Wing ECU - 934044$860.56Special order, ships in 7-14 days
18773542Ferrari Centralina Epc Can500 M - 773542$663.86Special order, ships in 7-14 days
18773444Ferrari Master Epc Unit For Fuel Pumps - 773444$614.67Special order, ships in 7-14 days
1916285227Ferrari Screw M5 x 20 - 16285227$0.59Available, ships in 3-6 days
20939577Ferrari TPMS ECU/Antenna - 939577$762.20Special order, ships in 7-14 days
20939579Ferrari Tpms Ecu/Antenna - 939579$762.20Special order, ships in 7-14 days
21854403Ferrari Tpms Antenna Mounting Bracke - 854403$44.24Special order, ships in 7-14 days
22773543Ferrari Centralina Epc Can500 S - 773543$663.86Special order, ships in 7-14 days
22773445Ferrari Slave Epc Unit For Fuel Pumps - 773445$614.67Special order, ships in 7-14 days
2355028859Ferrari Vehicle Lift Ecu - 55028859$1,524.44Special order, ships in 7-14 days
23847092Ferrari Vehicle Lift Ecu - 847092SupersededOrder 55028859 instead
23951586Ferrari Vehicle Lift Ecu - 951586SupersededOrder 55028859 instead
24960791Ferrari Lift System ECU Mounting Bra - 960791$218.81Special order, ships in 7-14 days
2585833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
