Ferrari 296 GTB — [ELECTRICAL SYSTEM] - F.08 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM (diagram 0183)

Exploded view of the [electrical system] - f.08 - various fastenings for the electrical system on the Ferrari 296 GTB, with 67 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 296 GTB [ELECTRICAL SYSTEM] - F.08 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
306631Ferrari Clip - 306631$7.59Special order, ships in 7-14 days
14569480Ferrari Clip 10x3.8 Black - 14569480$0.54Available, ships in 3-6 days
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
14039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
291225Ferrari P clip Bracket With Sheath - 291225$7.86Special order, ships in 7-14 days
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
1959003Ferrari LH Bracket - 959003$76.19Special order, ships in 7-14 days
214059111Ferrari Flanged Nut M5 - 14059111$0.08Available, ships in 3-6 days
214039511Ferrari Nut - 14039511$0.54Available, ships in 3-6 days
3175119Ferrari Bracket With Sheath - 175119$11.29Special order, ships in 7-14 days
416285127Ferrari Screw M5 x 16 - 16285127$1.05Special order, ships in 7-14 days
561712600Ferrari P Clip Bracket With Sheath D28 - 61712600$3.26Available, ships in 3-6 days
6179309Ferrari ADHESIVE FOAM - 179309$8.28Available, ships in 3-6 days
7898766Ferrari Ring Clamp - 898766$6.10Special order, ships in 7-14 days
8145854Ferrari Cable tie 200mm - 145854$0.57Available, ships in 3-6 days
9777725Ferrari Bracket - 777725$46.69Special order, ships in 7-14 days
10885989Ferrari Bracket - 885989$21.14Special order, ships in 7-14 days
11959751Ferrari Bracket - 959751$41.76Special order, ships in 7-14 days
1214059114Ferrari Nut M5 - 14059114$0.27Available, ships in 3-6 days
1385692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
1414059211Ferrari Flanged Nut - 14059211$0.13Available, ships in 3-6 days
1514040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
1661712500Ferrari P Clip Bracket - 61712500$2.29In stock
17306756Ferrari Clip - 306756$1.59Special order, ships in 7-14 days
1810448890Ferrari Bracket With Sheath - 10448890$4.16Available, ships in 3-6 days
18323137Ferrari Bracket With Sheath - 323137$46.69Special order, ships in 7-14 days
19217854Ferrari CLAMP - 217854$0.52Available, ships in 3-6 days
2014059311Ferrari NUT - 14059311$0.52Available, ships in 3-6 days
2185833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
22782674Ferrari Bracket With Sheath - 782674$10.54Special order, ships in 7-14 days
23248061Ferrari Clip - 248061$4.12Available, ships in 3-6 days
24935631Ferrari Torx Screw M8x12 - 935631$1.80Special order, ships in 7-14 days
25743009Ferrari Clip - 743009$1.48Special order, ships in 7-14 days
26866152Ferrari Clip - 866152$1.36Special order, ships in 7-14 days
2716287024Ferrari Screw - 16287024$1.00In stock
28972700Ferrari Compl. LH Bracket - 972700$61.45Special order, ships in 7-14 days
29751101Ferrari 4-Point Seat Harness Resisto - 751101$442.56Special order, ships in 7-14 days
3085692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
3114418924Ferrari Screw M4 x 8 TCEI - 14418924$1.04Available, ships in 3-6 days
32801702Ferrari RH Fuel Pump ECU Fix - 801702$39.31Special order, ships in 7-14 days
3316285227Ferrari Screw M5 x 20 - 16285227$0.59Available, ships in 3-6 days
34242384Ferrari Clip - 242384$0.59Available, ships in 3-6 days
35918833Ferrari Clip Hellermann Per Connetto - 918833$0.52Special order, ships in 7-14 days
36887433Ferrari Clip - 887433$2.13Special order, ships in 7-14 days
3710442290Ferrari P Clip Bracket With Sheath - 10442290$1.42Special order, ships in 7-14 days
38299418Ferrari Stud Bolt - 299418$7.63Special order, ships in 7-14 days
39918784Ferrari Clamp Hellermann Pa4.6 15 - 918784$0.82Special order, ships in 7-14 days
40786671Ferrari Clip - 786671$2.59Special order, ships in 7-14 days
40840252Ferrari RH Injection Cable Fastener - 840252SupersededOrder 786671 instead
4114084111Ferrari Nut - 14084111SupersededOrder 11673111 instead
42839788Ferrari Screw - 839788$1.72Special order, ships in 7-14 days
43231627Ferrari Screw M8 x 16 - 231627$1.25Available, ships in 3-6 days
44255869Ferrari Clip - 255869$3.91Special order, ships in 7-14 days
4516285924Ferrari Screw - 16285924$0.40Available, ships in 3-6 days
4685692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
48796026Ferrari Compl. Bracket - 796026$49.14Special order, ships in 7-14 days
49796023Ferrari Compl. Bracket - 796023$44.24Special order, ships in 7-14 days
50845487Ferrari Connector Fastener Bracket - 845487$39.31Special order, ships in 7-14 days
51869172Ferrari Body Cable Fastener Bracket - 869172$41.76Special order, ships in 7-14 days
52903093Ferrari Bracket - 903093$23.82Special order, ships in 7-14 days
5369708300Ferrari Clip - 69708300$2.59Available, ships in 3-6 days
55338712Ferrari Bracket With Sheath - 338712$4.89Special order, ships in 7-14 days
5611673111Ferrari Nut - 11673111$0.52Available, ships in 3-6 days
57920886Ferrari Retaining Clip - 920886$0.82Special order, ships in 7-14 days
58303385Ferrari Clip - 303385$0.57Special order, ships in 7-14 days
