Ferrari 296 GTS — [GENERAL] - A.01 - SPARE ASSEMBLY UNITS (diagram 0001)
Exploded view of the [general] - a.01 - spare assembly units on the Ferrari 296 GTS, with 5 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [GENERAL] - A.01 - SPARE ASSEMBLY UNITS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0001.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 985000364 | Ferrari Short Block - 985000364 | $62,624.30 | Contact us to order |
| 2 | 943874 | Ferrari Engine Gasket Set - 943874 | $2,294.87 | Special order, ships in 7-14 days |
| 3 | 762911 | Ferrari Cambio Gtc 498 Motore Post - 762911 | $65,269.33 | Contact us to order |
| 3 | 893170 | Ferrari Cambio Gtc 498 Motore Post - 893170 | Superseded | Order 762911 instead |
| 4 | 833550 | Ferrari Short Block Gasket Kit - 833550 | $442.56 | Special order, ships in 7-14 days |
