Ferrari 296 GTS — [ENGINE] - B.04 - CRANKSHAFT (diagram 0007)
Exploded view of the [engine] - b.04 - crankshaft on the Ferrari 296 GTS, with 19 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [ENGINE] - B.04 - CRANKSHAFT exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0007.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 979880 | Ferrari Crankshaft - 979880 | Superseded | Order 877663 instead | |
| 1 | 877663 | Ferrari Complete Crankshaft - 877663 | $4,570.37 | Special order, ships in 7-14 days |
| 2 | 176396 | Ferrari Threaded Plug D. 28 x 1.5 - 176396 | $10.42 | Available, ships in 3-6 days |
| 3 | 802414 | Ferrari Semicuscinetto Banco Sup Cro - 802414 | $54.07 | Special order, ships in 7-14 days |
| 3 | 798930 | Ferrari Semicuscinetto Banco Sup. Cr - 798930 | $54.07 | Special order, ships in 7-14 days |
| 3 | 798931 | Ferrari Semicuscinetto Banco Sup. Cr - 798931 | $54.07 | Special order, ships in 7-14 days |
| 3 | 798932 | Ferrari Semicuscinetto Banco Sup. Cr - 798932 | $54.07 | Special order, ships in 7-14 days |
| 3 | 798933 | Ferrari Semicuscinetto Banco Sup. Cr - 798933 | $54.07 | Special order, ships in 7-14 days |
| 3 | 802413 | Ferrari Semicuscinetto Banco Sup. Cr - 802413 | $54.07 | Special order, ships in 7-14 days |
| 3 | 853257 | Ferrari Semicuscinetto Banco Sup. Cr - 853257 | $54.07 | Special order, ships in 7-14 days |
| 4 | 798919 | Ferrari Lower Half Main Bearing - 798919 | $49.14 | Special order, ships in 7-14 days |
| 4 | 798920 | Ferrari Lower Half Main Bearing - 798920 | $49.14 | Special order, ships in 7-14 days |
| 4 | 798921 | Ferrari Lower Half Main Bearing - 798921 | $49.14 | Special order, ships in 7-14 days |
| 4 | 798922 | Ferrari Lower Half Main Bearing - 798922 | $49.14 | Special order, ships in 7-14 days |
| 4 | 802415 | Ferrari Lower Half Main Bearing - 802415 | $49.14 | Special order, ships in 7-14 days |
| 4 | 802416 | Ferrari Lower Half Main Bearing - 802416 | $49.14 | Special order, ships in 7-14 days |
| 4 | 853251 | Ferrari Lower Half Main Bearing - 853251 | $49.14 | Special order, ships in 7-14 days |
| 5 | 271589 | Ferrari Crankshaft Bearing Shim - 271589 | $24.07 | Available, ships in 3-6 days |
| 6 | 807599 | Ferrari Damper Alignment Pin - 807599 | $11.77 | Special order, ships in 7-14 days |
