Ferrari 296 GTS — [ENGINE] - B.12 - ENGINE OIL PUMP (diagram 0017)
Exploded view of the [engine] - b.12 - engine oil pump on the Ferrari 296 GTS, with 23 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [ENGINE] - B.12 - ENGINE OIL PUMP exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0017.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14306824 | Ferrari Bolt M8 x 45 TCEI - 14306824 | $1.04 | Available, ships in 3-6 days | |
| 1 | 55041454 | Ferrari Compl. Oil Pump - 55041454 | $7,693.94 | Special order, ships in 7-14 days |
| 1 | 762665 | Ferrari Compl. Oil Pump - 762665 | Superseded | Order 55041454 instead |
| 1 | 864150 | Ferrari Compl. Oil Pump - 864150 | Superseded | Order 55041454 instead |
| 1 | 968943 | Ferrari Compl. Oil Pump - 968943 | Superseded | Order 55041454 instead |
| 2 | 965552 | Ferrari Oil Recovery Pump Filter - 965552 | $85.22 | Special order, ships in 7-14 days |
| 3 | 14302124 | Ferrari Allen Head Bolt M 8X100 - 14302124 | $2.59 | Special order, ships in 7-14 days |
| 4 | 986847 | Ferrari Conical Washer - 986847 | $1.36 | Special order, ships in 7-14 days |
| 4 | 986899 | Ferrari Washer - 986899 | Superseded | Order 986847 instead |
| 4 | 11198074 | Ferrari/Maserati Washer - 11198074 | $0.14 | In stock |
| 5 | 285494 | Ferrari Screw 8x50 - 285494 | $1.99 | Available, ships in 3-6 days |
| 6 | 804067 | Ferrari Check Valve - 804067 | $164.72 | Special order, ships in 7-14 days |
| 6 | 814336 | Ferrari Check Valve - 814336 | $189.31 | Special order, ships in 7-14 days |
| 6 | 834674 | Ferrari Check Valve - 834674 | Price on request | Contact us for price and availability |
| 7 | 949381 | Ferrari Hexagonal Oil Pump Drive Rod - 949381 | $125.37 | Special order, ships in 7-14 days |
| 8 | 804074 | Ferrari Calibrated Screw - 804074 | $63.37 | Special order, ships in 7-14 days |
| 8 | 864151 | Ferrari Screw - 864151 | $56.54 | Special order, ships in 7-14 days |
| 9 | 866272 | Ferrari Oil Pump Bushing Mounting Br - 866272 | $27.03 | Special order, ships in 7-14 days |
| 9 | 910598 | Ferrari Oil Pump Bushing Mounting Br - 910598 | $46.48 | Special order, ships in 7-14 days |
| 10 | 282391 | Ferrari Screw - 282391 | $1.80 | Special order, ships in 7-14 days |
| 11 | 335148 | Ferrari O-Ring - 335148 | $3.91 | Special order, ships in 7-14 days |
| 12 | 335150 | Ferrari O-Ring - 335150 | $3.91 | Special order, ships in 7-14 days |
| 14 | 908932 | Ferrari Bushing - 908932 | $440.57 | Special order, ships in 7-14 days |
