Ferrari 296 GTS — [ENGINE] - B.14 - ENGINE INTAKE DUCT (diagram 0019)
Exploded view of the [engine] - b.14 - engine intake duct on the Ferrari 296 GTS, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [ENGINE] - B.14 - ENGINE INTAKE DUCT exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0019.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14432221 | Ferrari Screw - 14432221 | Superseded | Order 231619 instead | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 14432224 | Ferrari Screw M6 x 22 - 14432224 | Superseded | Order 231619 instead | |
| 1 | 864303 | Ferrari Compl. LH Intake Manifold - 864303 | $565.49 | Special order, ships in 7-14 days |
| 1 | 864301 | Ferrari Compl. RH Intake Manifold - 864301 | $565.49 | Special order, ships in 7-14 days |
| 2 | 911401 | Ferrari LH Plenum Flange Gasket - 911401 | $83.57 | Special order, ships in 7-14 days |
| 2 | 911528 | Ferrari RH Plenum Flange Gasket - 911528 | $83.57 | Special order, ships in 7-14 days |
| 3 | 917745 | Ferrari Gasket - 917745 | $41.76 | Special order, ships in 7-14 days |
| 4 | 868194 | Ferrari Plenum Oil Drain Plug - 868194 | $22.60 | Special order, ships in 7-14 days |
| 5 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 6 | 177593 | Ferrari O-Ring - 177593 | $9.16 | Special order, ships in 7-14 days |
| 7 | 835465 | Ferrari Pressure And Temperature Sen - 835465 | $83.03 | Special order, ships in 7-14 days |
| 8 | 231619 | Ferrari Screw M6 x 22 - 231619 | $0.54 | Available, ships in 3-6 days |
