Ferrari 296 GTS — [ENGINE] - B.15 - INJECTION CONTROL (diagram 0020)

Exploded view of the [engine] - b.15 - injection control on the Ferrari 296 GTS, with 2 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 296 GTS [ENGINE] - B.15 - INJECTION CONTROL exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
1743252Ferrari Corpo Farfallato Motorizz - 743252$737.61Special order, ships in 7-14 days
2231624Ferrari Allen Screw M6 x 45 - 231624SupersededOrder 14305924 instead
