Ferrari 296 GTS — [ENGINE] - B.18 - FUEL PUMPS (diagram 0023)
Exploded view of the [engine] - b.18 - fuel pumps on the Ferrari 296 GTS, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [ENGINE] - B.18 - FUEL PUMPS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0023.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 878119 | Ferrari Pompa Benzina A.P. Hdp6 Tra - 878119 | $1,027.22 | Special order, ships in 7-14 days |
| 2 | 331787 | Ferrari HIGH PRESSURE PUMP CAM FOLLOWER - 331787 | $105.70 | Special order, ships in 7-14 days |
| 3 | 14306434 | Ferrari Screw M8x25 - 14306434 | $0.71 | Special order, ships in 7-14 days |
| 4 | 12638524 | Ferrari Flat Washer 8.15x15x1.5 - 12638524 | $0.12 | Available, ships in 3-6 days |
| 5 | 876113 | Ferrari Fuel Pipe - 876113 | $162.25 | Available, ships in 3-6 days |
| 6 | 859262 | Ferrari Pump Soundproofing Cover - 859262 | $319.62 | Special order, ships in 7-14 days |
| 7 | 763134 | Ferrari Fuel Pump Seal - 763134 | $6.96 | Special order, ships in 7-14 days |
