Ferrari 296 GTS — [ENGINE] - B.26 - ENGINE HEAT EXCHANGER (diagram 0031)
Exploded view of the [engine] - b.26 - engine heat exchanger on the Ferrari 296 GTS, with 8 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [ENGINE] - B.26 - ENGINE HEAT EXCHANGER exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0031.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 216568 | Ferrari Screw 6x30 - 216568 | Superseded | Order 231621 instead | |
| 1 | 776450 | Ferrari Heat Exchanger - 776450 | $1,598.19 | Special order, ships in 7-14 days |
| 2 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 3 | 778452 | Ferrari Heat Exchanger Gasket - 778452 | $9.37 | Special order, ships in 7-14 days |
| 4 | 745881 | Ferrari Filler For Under Heat Exchan - 745881 | $393.38 | Special order, ships in 7-14 days |
| 4 | 987940 | Ferrari Filler For Under Heat Exchan - 987940 | $181.93 | Special order, ships in 7-14 days |
| 5 | 231621 | Ferrari Allen Screw M6 x 30 TCEI - 231621 | $0.73 | Available, ships in 3-6 days |
