Ferrari 296 GTS — [MECHANICAL SYSTEM] - D.12 - TANK MOUNTS (diagram 0061)
Exploded view of the [mechanical system] - d.12 - tank mounts on the Ferrari 296 GTS, with 19 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [MECHANICAL SYSTEM] - D.12 - TANK MOUNTS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0061.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14498804 | Ferrari Washer - 14498804 | Superseded | Order 14498824 instead | |
| 1 | 963428 | Ferrari Isolante Termico Serbatoi - 963428 | $344.21 | Special order, ships in 7-14 days |
| 2 | 961534 | Ferrari Isolante Termico Serbatoi - 961534 | $344.21 | Special order, ships in 7-14 days |
| 3 | 811842 | Ferrari RH Rear Retainer - 811842 | $189.31 | Special order, ships in 7-14 days |
| 4 | 811828 | Ferrari LH Rear Retainer - 811828 | $189.31 | Special order, ships in 7-14 days |
| 5 | 792394 | Ferrari Screw TE M6 x 18 - 792394 | $0.84 | Available, ships in 3-6 days |
| 6 | 965951 | Ferrari RH Front Retainer - 965951 | $88.49 | Special order, ships in 7-14 days |
| 7 | 965949 | Ferrari LH Front Retainer - 965949 | $90.95 | Special order, ships in 7-14 days |
| 8 | 907328 | Ferrari RH Lower Support - 907328 | $231.09 | Special order, ships in 7-14 days |
| 9 | 965945 | Ferrari LH Lower Support - 965945 | $295.03 | Special order, ships in 7-14 days |
| 10 | 14040614 | Ferrari Flanged Nut 6mm - 14040614 | $0.27 | Available, ships in 3-6 days |
| 11 | 81923100 | Ferrari Screw - 81923100 | $1.15 | Available, ships in 3-6 days |
| 12 | 12640624 | Ferrari Plain Washer 6mm - 12640624 | $0.31 | Available, ships in 3-6 days |
| 13 | 965940 | Ferrari Rear Tank Retainer - 965940 | $108.16 | Special order, ships in 7-14 days |
| 14 | 67315400 | Ferrari Washer - 67315400 | $0.82 | Special order, ships in 7-14 days |
| 15 | 83222200 | Ferrari Fastener Button - 83222200 | $1.42 | Available, ships in 3-6 days |
| 16 | 16281824 | Ferrari Screw - 16281824 | $0.82 | Available, ships in 3-6 days |
| 17 | 14447078 | Ferrari Washer D. 5.5 - 15 x 1 - 14447078 | $0.54 | Special order, ships in 7-14 days |
| 18 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
