Ferrari 296 GTS — [VEHICLE TRIM] - E.06 - LATERAL SUBSTRUCTURE (diagram 0102)
Exploded view of the [vehicle trim] - e.06 - lateral substructure on the Ferrari 296 GTS, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.06 - LATERAL SUBSTRUCTURE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0102.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 985952617 | Ferrari Compl. RH A Pillar Flange - 985952617 | $442.56 | Special order, ships in 7-14 days |
| 2 | 985952609 | Ferrari Compl. LH A Pillar Flange - 985952609 | $442.56 | Special order, ships in 7-14 days |
| 3 | 985952612 | Ferrari RH Front Panel - 985952612 | $368.79 | Special order, ships in 7-14 days |
| 4 | 985952611 | Ferrari LH Front Panel - 985952611 | $368.79 | Special order, ships in 7-14 days |
| 5 | 985952613 | Ferrari Rear RH Endpiece - 985952613 | $368.79 | Special order, ships in 7-14 days |
| 6 | 985952614 | Ferrari Rear LH Endpiece - 985952614 | $368.79 | Special order, ships in 7-14 days |
