Ferrari 296 GTS — [VEHICLE TRIM] - E.10 - REAR LID SUBSTRUCTURE (diagram 0106)
Exploded view of the [vehicle trim] - e.10 - rear lid substructure on the Ferrari 296 GTS, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.10 - REAR LID SUBSTRUCTURE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0106.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 985776117 | Ferrari Compl. Rear Lid Substructure - 985776117 | $1,598.19 | Special order, ships in 7-14 days |
| 2 | 921604 | Ferrari RH Engine Compartment Lid Hi - 921604 | $516.33 | Special order, ships in 7-14 days |
| 3 | 921680 | Ferrari LH Engine Compartment Lid Hi - 921680 | $516.33 | Special order, ships in 7-14 days |
| 4 | 16043534 | Ferrari Screw M8 x 22 - 16043534 | $0.65 | Available, ships in 3-6 days |
| 5 | 12646727 | Ferrari Washer D. 8.45 X 20 X 2 - 12646727 | $0.40 | Available, ships in 3-6 days |
| 6 | 82271400 | Ferrari Screw with Washer M8 x 25 TE - 82271400 | $2.59 | Available, ships in 3-6 days |
