Ferrari 296 GTS — [VEHICLE TRIM] - E.12 - ROLLBAR (diagram 0108)
Exploded view of the [vehicle trim] - e.12 - rollbar on the Ferrari 296 GTS, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.12 - ROLLBAR exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0108.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12640606 | Ferrari Washer - 12640606 | Superseded | Order 12640678 instead | |
| 12640608 | Ferrari Washer - 12640608 | Superseded | Order 12640678 instead | |
| 12640677 | Ferrari Washer - 12640677 | Superseded | Order 12640678 instead | |
| 1 | 800204 | Ferrari Part Search Results - 800204 | $565.49 | Special order, ships in 7-14 days |
| 2 | 800200 | Ferrari LH B-Pillar Connector Reinfo - 800200 | $565.49 | Special order, ships in 7-14 days |
| 3 | 13046214 | Ferrari Nut - 13046214 | $0.73 | Special order, ships in 7-14 days |
| 4 | 791263 | Ferrari Flanged Screw M6 x 45 - 791263 | $0.82 | Special order, ships in 7-14 days |
| 5 | 12640678 | Ferrari Washer 6.15x25x2 - 12640678 | $3.47 | Available, ships in 3-6 days |
| 6 | 903295 | Ferrari Screw - 903295 | $1.42 | Special order, ships in 7-14 days |
| 7 | 13578301 | Ferrari Washer - 13578301 | $0.17 | Special order, ships in 7-14 days |
