Ferrari 296 GTS — [VEHICLE TRIM] - E.13.04 - ROOF - HYDRAULICS (diagram 0112)
Exploded view of the [vehicle trim] - e.13.04 - roof - hydraulics on the Ferrari 296 GTS, with 5 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.13.04 - ROOF - HYDRAULICS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0112.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 903686 | Ferrari Complete Hydraulic System Kit - 903686 | $18,044.06 | Special order, ships in 7-14 days |
| 2 | 903676 | Ferrari Roof Wiring Harness - 903676 | $1,032.68 | Special order, ships in 7-14 days |
| 3 | 977275 | Ferrari Ecu - 977275 | Superseded | Order 999621 instead |
| 3 | 999621 | Ferrari NCP ECU - 999621 | $1,770.31 | Special order, ships in 7-14 days |
| 4 | 84603200 | Ferrari Hydraulic System Fastener Kit - 84603200 | $115.54 | Special order, ships in 7-14 days |
