Ferrari 296 GTS — [VEHICLE TRIM] - E.19 - INTERNAL CABIN INSULATION (diagram 0118)
Exploded view of the [vehicle trim] - e.19 - internal cabin insulation on the Ferrari 296 GTS, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.19 - INTERNAL CABIN INSULATION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0118.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 902450 | Ferrari LH Firewall Insulation - 902450 | $236.02 | Special order, ships in 7-14 days | |
| 970446 | Ferrari RH Firewall Insulation - 970446 | Superseded | Order 747990 instead | |
| 1 | 747990 | Ferrari RH Firewall Insulation - 747990 | $393.38 | Special order, ships in 7-14 days |
| 1 | 902457 | Ferrari RH Firewall Insulation - 902457 | $236.02 | Special order, ships in 7-14 days |
| 2 | 747991 | Ferrari LH Firewall Insulation - 747991 | $236.02 | Special order, ships in 7-14 days |
| 2 | 907321 | Ferrari LH Firewall Insulation - 907321 | $194.22 | Special order, ships in 7-14 days |
| 3 | 970445 | Ferrari Valence Insulation - 970445 | $86.04 | Special order, ships in 7-14 days |
| 4 | 67315400 | Ferrari Washer - 67315400 | $0.82 | Special order, ships in 7-14 days |
| 5 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 6 | 782601 | Ferrari Foot-Rest For Driver Insulat - 782601 | $36.86 | Special order, ships in 7-14 days |
| 6 | 970447 | Ferrari LH Driver Footrest Insulatio - 970447 | $34.40 | Special order, ships in 7-14 days |
| 7 | 911129 | Ferrari Accelerator Bracket Insulation - 911129 | $31.93 | Special order, ships in 7-14 days |
| 8 | 890171 | Ferrari Grub Screw - 890171 | $2.82 | Special order, ships in 7-14 days |
