Ferrari 296 GTS — [VEHICLE TRIM] - E.22 - FRONT AIR INTAKES (diagram 0121)
Exploded view of the [vehicle trim] - e.22 - front air intakes on the Ferrari 296 GTS, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.22 - FRONT AIR INTAKES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0121.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 980705 | Ferrari Compl. LH Front Duct - 980705 | Superseded | Order 826782 instead | |
| 980704 | Ferrari Compl. RH Front Duct - 980704 | Superseded | Order 826785 instead | |
| 1 | 826785 | Ferrari Compl. RH Front Duct - 826785 | $221.26 | Special order, ships in 7-14 days |
| 2 | 826782 | Ferrari Compl. LH Front Duct - 826782 | $221.26 | Special order, ships in 7-14 days |
| 3 | 980721 | Ferrari Compl. RH Brake Air Duct - 980721 | $319.62 | Special order, ships in 7-14 days |
| 4 | 980722 | Ferrari Compl. LH Brake Air Duct - 980722 | $319.62 | Special order, ships in 7-14 days |
| 5 | 80874100 | Ferrari Screw Torx - 80874100 | $1.97 | Available, ships in 3-6 days |
| 6 | 11625824 | Ferrari Screw 6x18 - 11625824 | $0.71 | Available, ships in 3-6 days |
| 7 | 10523107 | Ferrari Washer - 10523107 | $5.44 | Available, ships in 3-6 days |
